The GE IC200MDL632D Digital Output Module is a key component of the Versamax PLC series, providing advanced control for high-performance digital outputs in industrial automation systems. Designed to handle 32 digital outputs with a sourcing configuration, this module is ideal for controlling high-power devices such as motors, relays, and solenoids. Offering precise and reliable control in demanding applications, the IC200MDL632D is built for use in various industries, including manufacturing, process control, and material handling. With its rugged construction and robust performance, this module ensures smooth operations in high-demand environments, making it a crucial part of any scalable automation system.

Technical Specifications

Model: IC200MDL632D
Type: Digital Output Module
Output Type: 24V DC sourcing outputs
Output Points: 32 digital outputs
Voltage Range: 20.4V DC to 28.8V DC
Current Rating: 0.5A per output channel (maximum)
Power Consumption: 75mA @ 24V DC
Mounting: DIN rail or panel mount
Dimensions: 4.75" x 6.25" x 3.5" (121 mm x 159 mm x 89 mm)
Weight: 0.75 lbs (0.34 kg)
Operating Temperature: 0°C to 60°C
Storage Temperature: -40°C to 85°C
Relative Humidity: 5% to 95%, non-condensing
Isolation: 1500V RMS

Recommended Related Models

To enhance the capabilities of your Versamax PLC system, consider adding these complementary modules:

IC200CPUE06: A high-performance CPU module with increased memory and I/O capabilities for more complex systems.
IC200GBI001: A digital input module that can capture 16 digital input signals from various field devices.
IC200PWR001: Power supply module that provides stable voltage for the entire system.
IC200ERM002A: Communication module offering Ethernet and Modbus capabilities for easy network integration.

Popular GE PLC Models

The Versamax PLC series is known for its flexibility and scalability, with several popular models designed to suit various applications:

IC200CPUE05-LT: Ideal for small to medium automation systems, offering a cost-effective solution for general-purpose tasks.
IC200CPUE06: A powerful CPU for handling more complex and larger-scale automation applications.
IC200MDL640: A reliable digital I/O module that provides additional input/output points for scaling your system.

Applications

The GE IC200MDL632D Digital Output Module is designed for a variety of applications where high-performance and reliable output control are essential:

Manufacturing Automation: Controls motors, solenoids, and valves to automate processes on production lines.
Process Control: Manages output devices for controlling valves, pumps, and other equipment in chemical plants or water treatment facilities.
Material Handling: Interfaces with actuators and robotic arms in material transport systems to enable smooth operation.
Building Automation: Controls lighting, HVAC, and other environmental systems in large commercial or industrial buildings.

Advantages

High Output Capacity: The IC200MDL632D offers 32 digital outputs, providing increased flexibility for larger systems.
Sourcing Output Type: With sourcing outputs, this module is ideal for controlling external devices that require a positive voltage to activate, ensuring wide compatibility.
Rugged Design: Built for use in industrial environments with an operating temperature range of 0°C to 60°C, it can withstand the demands of a variety of applications.
Easy Integration: The module supports quick installation on DIN rails or panel mounting, allowing for flexibility in different control panel designs.
Cost-Effective Expansion: Expands the output capabilities of your Versamax PLC system without the need for additional complex systems.

Technical FAQs

How many digital outputs does the IC200MDL632D module support?
The IC200MDL632D supports 32 digital outputs, ideal for controlling multiple external devices at once.
What is the maximum current rating for each output channel?
Each output channel can handle up to 0.5A, making it suitable for controlling motors, relays, and solenoids.
What is the output type of the IC200MDL632D module?
The module provides 24V DC sourcing outputs, suitable for driving devices that require a positive voltage signal.
What is the voltage range supported by this module?
The module operates with an input voltage range of 20.4V DC to 28.8V DC.
How much power does the IC200MDL632D consume?
The module consumes 75mA at 24V DC during normal operation.
Can the IC200MDL632D be used to control high-power devices directly?
The IC200MDL632D is ideal for low-to-moderate power devices, but for high-power devices, it is recommended to use relays or external control devices.
What is the isolation rating for this module?
The IC200MDL632D provides 1500V RMS isolation to protect the system from electrical noise and surges.
What is the recommended operating temperature range for this module?
The IC200MDL632D operates between 0°C and 60°C, making it suitable for a wide range of industrial environments.
What kind of mounting options are available for this module?
The module can be mounted on DIN rails or panel-mounted, offering flexibility for different installation setups.
How is this module programmed or configured?
The IC200MDL632D is configured using Proficy Machine Edition software, which simplifies programming and integration with your Versamax PLC system.
