The GE IC200MDL730 Digital Output Module is a reliable and high-performance output solution designed for use with the VersaMax PLC system. This module offers 32 output points with 24 VDC output voltage, utilizing PNP sourcing outputs. It provides the necessary interface for controlling devices such as relays, solenoids, actuators, and lights in industrial automation systems. Whether you’re managing a manufacturing process, controlling machinery, or automating any industrial application, the IC200MDL730 ensures precise control and integration with other system components. With its compact design and high-density output capability, it is perfect for applications requiring multiple output signals in a space-efficient manner.

Technical Specifications

Feature	Specification
Model Number	IC200MDL730
Module Type	Digital Output Module
Output Voltage	24 VDC
Output Type	Sourcing (PNP)
Outputs per Module	32 (8 points per channel, 4 channels)
Nominal Output Current	0.5 A per point
Dimensions (W x D x H)	3.7 x 3.1 x 5.0 inches (94 x 79 x 127 mm)
Weight	0.5 lbs (0.23 kg)
Operating Temperature Range	0°C to 60°C
Storage Temperature Range	-40°C to 85°C
Mounting	Snap-on to the VersaMax I/O rack
Status Indicators	LED indicators for output status

Recommended Related Models

To maximize the capabilities of the IC200MDL730, consider the following complementary modules:

GE IC200MDL640: Digital Input Module to collect data from various sensors and switches and feed it into the VersaMax system.
GE IC200CMM002: Communication Module for linking the VersaMax PLC to other systems or networks, enabling data sharing and remote control.
GE IC200MDL740: A higher-density digital output module for applications that require additional output points in the same system.

These modules can help extend the functionality of your automation system, enabling more complex and efficient control.

Popular GE Models

IC200PWR001: Power Supply Module to provide stable power for the entire VersaMax PLC system.
IC200ERM001: Ethernet Communication Module for reliable network communication.
IC200MDL640: Digital Input Module designed for use in conjunction with output modules like the IC200MDL730 for seamless control and monitoring.
IC200UDR001: Universal Digital Relay Module, offering flexibility for digital relay tasks.

These models work synergistically with the IC200MDL730, allowing you to customize and expand your automation system based on specific needs.

Applications

The GE IC200MDL730 Digital Output Module is ideal for a broad range of industrial applications, including:

Manufacturing Automation: Controls actuators, relays, solenoids, and other devices that manage production processes and operations.
Process Control: Used to regulate processes in industries like chemical, food, and pharmaceuticals, where accurate and reliable outputs are critical.
Machine Control: Interfaces with machines to control components based on digital input signals, ensuring smooth and consistent operation.
Building Automation: Enables control of lighting systems, HVAC units, and other automated building systems.

The high output density and flexibility of this module make it an excellent choice for complex systems requiring precise control over multiple devices.

Advantages

High Output Density: The IC200MDL730 offers 32 outputs in a single module, allowing you to manage a large number of devices without requiring additional space.
Compact and Efficient: Despite its high output count, the module’s small size allows for efficient use of panel space, making it ideal for installations where space is at a premium.
Precise Control: The PNP sourcing output ensures reliable control of a variety of field devices, improving the accuracy and consistency of your automation systems.
Ease of Installation: The snap-on mounting system simplifies the installation process, reducing setup time and minimizing the chance of errors.
Cost-Effective: Provides a high level of performance and flexibility at a competitive price, offering great value for large-scale industrial automation projects.

Technical FAQs

What is the nominal output voltage for the IC200MDL730?
The module provides 24 VDC output voltage.
How many outputs does the IC200MDL730 support?
It supports up to 32 outputs, distributed across 4 channels, with 8 points per channel.
What type of outputs does this module provide?
The IC200MDL730 uses PNP sourcing outputs, ideal for controlling devices such as solenoids and relays.
What is the operating temperature range for the IC200MDL730?
The module operates within the temperature range of 0°C to 60°C.
How is the IC200MDL730 mounted in the system?
The module is designed for snap-on mounting into the VersaMax I/O rack, making installation fast and easy.
Does the IC200MDL730 require an external power supply?
Yes, it requires a 24 VDC power supply for operation.
What is the maximum output current per point?
Each output can handle up to 0.5 A of current.
Can the IC200MDL730 handle high-speed output applications?
While not specifically designed for high-speed applications, the module is suitable for most general output tasks in industrial automation.
What is the weight of the IC200MDL730?
The module weighs approximately 0.5 lbs (0.23 kg).
Does the IC200MDL730 have any status indicators?
Yes, the module includes LED indicators that show the operational status of each output.
