The GE IC200PNS001-AC is a high-performance PROFINET Scanner Network Interface Module engineered to bridge GE’s VersaMax I/O ecosystem with modern Ethernet-based PROFINET control networks. Built for industrial automation environments where distributed I/O, real-time communication, and flexible topology options are critical, this module enables scalable remote I/O architectures with robust diagnostics and easy integration. Its dual Ethernet interfaces, configurable update rates, and compact industrial packaging make it an excellent component for machine builders and system integrators seeking dependable Ethernet-connected I/O solutions.

Technical Specifications

Parameter	Description
Module Type	PROFINET Scanner / Network Interface
Supported Protocol	PROFINET Version 2.2 Class A I/O-Device
Ethernet Ports	2 × 10/100 Mbps RJ45 (embedded switch)
I/O Data Capacity	Up to 2880 bytes total (1440 in/1440 out)
I/O Update Rate	Configurable: 1 ms – 512 ms
Power Supply	24 V DC nominal
Power Consumption	~0.60 A @ 5 V DC (backplane)
Mounting	DIN rail or panel via VersaMax carrier
Approx. Dimensions (H × W × D)	~132 × 134 × 68 mm
Approx. Weight	~0.26 kg
Operating Temp.	0 – 60 °C
Status LEDs	Module, network, and I/O indicators

This module supports standard PROFINET topologies, including linear, star, and ring (with redundancy), and offers flexible I/O update rates to match application determinism requirements.

Recommended Related Models

Model	Description
IC200MDL740	16-point DC digital input module
IC200MDL741B	16-point DC discrete output module
IC200MDL742H	High-density DC output module
IC200PWR001	VersaMax main DC power supply module

Popular GE (Emerson) System Components

Category	Representative Models
CPU Controllers	IC200CPU001, IC200CPU002
Network Interfaces	IC200PNS001, IC200PNS002
I/O Carriers	IC200CHS010, IC200CHS044
Analog Modules	IC200ALGxxx series

Applications

The IC200PNS001-AC is deployed in industrial automation environments where seamless PROFINET connectivity between distributed I/O and central controllers is required. Typical applications include:

Production line control stations connecting remote I/O nodes to PROFINET controllers
Packaging, assembly, and material handling systems demanding real-time network I/O
Industrial process control with Ethernet-based diagnostics and status monitoring
Retrofitting traditional VersaMax I/O systems into modern Ethernet infrastructures

Its ability to handle sizable I/O datasets and configurable update rates makes it suitable for large systems with tight synchronization needs.

Advantages

Native PROFINET support ensures real-time communication with automation controllers
Dual Ethernet ports with embedded switching reduce wiring complexity and support flexible topologies (line, star, ring)
Configurable I/O update rates adapt to application determinism requirements
Compact industrial design fits standard control cabinets and DIN rail mounts
Clear diagnostics via LEDs accelerate commissioning and fault identification
Scalable I/O capacity up to eight modules per node, simplifying distributed architecture design

Technical FAQs

What protocol does the IC200PNS001-AC support?
It supports PROFINET Version 2.2 Class A I/O-Device communication.
How many Ethernet ports are available?
Two 10/100 Mbps RJ45 ports with embedded switching are included.
What power supply does this module require?
It uses a 24 V DC nominal supply through the VersaMax backplane.
What is the typical operating temperature range?
The module is designed to operate from 0 °C to 60 °C.
Can the I/O update rate be adjusted?
Yes — it’s configurable from 1 ms to 512 ms to match control requirements.
Does this module support redundant network topologies?
Yes — linear, star, and ring (redundancy) topologies are supported.
How many I/O modules can this scanner handle?
It supports up to eight VersaMax I/O modules in a remote node.
Is there built-in diagnostic feedback?
Yes — status LEDs for module health, network link, and I/O conditions are provided.
Can firmware be updated?
Yes — firmware updates can be applied via USB (not for permanent connection).
Where is this module commonly mounted?
It mounts on a DIN rail or panel using an appropriate VersaMax carrier.
