The GE IC695ALG704 Analog Input Module is a high-density, industrial analog interface designed for the PACSystems RX3i control platform. With 32 isolated analog input channels, this module is ideal for advanced automation applications that require large-scale data acquisition with dependable precision and robust electrical isolation.

Where systems demand high channel counts without sacrificing measurement fidelity, the IC695ALG704 delivers scalable performance. Its design focuses on electrical noise immunity, accurate signal conversion, and advanced diagnostics — making it a strong choice for utilities, process industries, and complex manufacturing environments.

Technical Specifications

Parameter Specification
Module Type 32-Channel Isolated Analog Input
Compatible Platform PACSystems RX3i
Number of Input Channels 32 isolated analog inputs
Supported Signal Types Voltage and Current
Voltage Ranges 0–5 V, 1–5 V, 0–10 V, ±10 V
Current Ranges 0–20 mA, 4–20 mA
Conversion Method Sigma-Delta A/D
Resolution Up to 16-bit
Isolation Individual channel isolation
Input Filtering Software configurable
Diagnostic Features Over-range, under-range, open-circuit detection
Backplane Power Requirement 5 V DC
Operating Temperature 0°C to +60°C
Storage Temperature −40°C to +85°C
Dimensions (L×W×H) 145×34×140 mm
Weight Approx. 1.1 kg

Recommended Related Models

GE IC695CPU315 – RX3i CPU Module

GE IC695PWR330 – Power Supply Module

GE IC695BEM331 – Ethernet Communication Module

GE IC695ALG600 – Universal Analog Input Module

GE IC695CHS398 – 18-Slot Universal Backplane

Popular GE Analog & I/O Modules

GE IC695ALG608 – 8-Channel Isolated Analog Input Module

GE IC695ALG616 – 16-Channel Analog Input Module

GE IC695MDL753 – 32-Point Digital Output Module

GE IC694PWR321 – Power Supply Module

GE IC695ETM001 – Ethernet Interface Module

Typical Applications

The IC695ALG704 is suited to applications with high channel count requirements and strict measurement accuracy:

Process control systems in power plants
Large-scale energy monitoring systems
Oil & gas facility automation and instrumentation
Industrial chemical production facilities
Automated manufacturing and fabrication environments

With 32 channels in one module, it enables compact rack design and simplifies engineering configuration in projects requiring extensive analog input capacity.

Typical Applications

The IC695ALG704 is suited to applications with high channel count requirements and strict measurement accuracy:

Process control systems in power plants
Large-scale energy monitoring systems
Oil & gas facility automation and instrumentation
Industrial chemical production facilities
Automated manufacturing and fabrication environments

With 32 channels in one module, it enables compact rack design and simplifies engineering configuration in projects requiring extensive analog input capacity.

Technical FAQs

1. How many analog channels does the IC695ALG704 have?
It has 32 individually isolated analog input channels.

2. Does it support both voltage and current signals?
Yes, it supports standard industrial voltage and current ranges.

3. What resolution does the module provide?
Up to 16-bit resolution depending on configuration.

4. Is channel isolation provided?
Yes, channels are individually isolated for noise immunity.

5. Can it operate in harsh industrial conditions?
Yes, it is rated for 0°C to +60°C industrial environments.

6. Does it provide diagnostic feedback?
Yes, it includes over-range, under-range, and open-circuit diagnostics.

7. What platform is it compatible with?
It is designed for PACSystems RX3i PLC systems.

8. Can it reduce system hardware footprint?
Yes, its high channel count reduces the number of required modules.

9. Is it suitable for large data acquisition projects?
Yes, it is ideal for applications requiring extensive analog inputs.

10. Does it integrate with advanced control strategies?
Yes, it works seamlessly within scalable RX3i architectures.
