The GE IS200TVIBH2B Turbine Vibration Input & Bridge Handler (TVIB) Module is a specialized signal acquisition and conditioning board designed for integration within GE Mark VI and EX2100 turbine control systems. This module focuses on capturing, filtering, and processing vibration sensor inputs and related analog signals. Its primary role is to provide accurate, conditioned feedback from turbine vibration pickups to the control logic, enabling early detection of imbalance, bearing issues, or mechanical resonance.
In high-performance turbine environments where equipment health and protection are paramount, the IS200TVIBH2B supports reliable vibration monitoring and integrates seamlessly with protective logic and supervisory systems.
Technical Specifications
| Specification | Details |
|---|---|
| Model | IS200TVIBH2B |
| Brand | GE |
| Module Type | Turbine Vibration Input & Bridge Handler Module |
| System Compatibility | GE Mark VI / EX2100 Control Systems |
| Primary Function | Acquisition & conditioning of vibration feedback signals |
| Input Signal Types | Vibration transducers, accelerometers, analog bridge sensors |
| Signal Conditioning | Filtering, isolation buffering, noise suppression |
| Protection Features | Transient suppression & EMI/RFI resilience |
| Mounting | Rack / backplane mounted in control cabinet |
| Operating Environment | Industrial power generation environments |
| Dimensions (L × W × H) | 250 × 120 × 35 mm (approx.) |
| Weight | 0.92 kg (approx.) |
This board converts raw vibration sensor data into clean, logic-ready signals for turbine health monitoring and protective algorithms.
Recommended Related Models
For comprehensive vibration and protection processing, the IS200TVIBH2B is often deployed with:
-
IS200DSPXH1D – Digital Signal Processor Control Board
-
IS200TPROH1C – Turbine Protection Logic Module
-
IS200STCIH2A – Status & Timing Control Input Handler
-
IS200STAOH2A – Status & Timing Output Handler
-
IS200TBTCH1C – Turbine Terminal Board
Together, these modules provide coordinated vibration input, logic processing, protection decisioning, and output signaling.
Popular GE Mark VI / EX2100 Modules
Common modules used alongside the IS200TVIBH2B include:
-
IS200EACFG3A – AC Feedback Conditioning Board
-
IS200EDCFG1B – DC Feedback Board
-
IS200EXHSG3A – High-Speed Gate Control Board
-
IS200IGPAG2A – IGBT Gate Pulse Amplifier Board
-
IS200ERBPG1A – Remote I/O Backplane Module
These boards support essential control, actuation, and feedback tasks in turbine and excitation systems.
