ABB TA564-11 Terminal Block for AC500-eCo PLC I/O Wiring Interfaces
ABB TA564-11 Terminal Block for AC500-eCo PLC I/O Wiring Interfaces
0.0
Points
Brand:ABB PLC Item No.:ABB TA564-11 Product Origin:Sweden Product Dimensions:40 × 150 × 250 mm Product Weight:0.036 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB TA564-11 Terminal Block is a compact wiring interface accessory designed for ABB AC500-eCo PLC systems and S500-eCo I/O modules. It provides a reliable connection point between field wiring and PLC modules, allowing sensors, actuators, and control signals to be safely integrated into the automation system.
This terminal block features a front-screw and front-cable design, making wiring straightforward during installation and maintenance. With its 11-pole configuration, the module simplifies structured wiring layouts in control panels and ensures secure electrical connections even in demanding industrial environments.
Designed to meet industrial reliability standards, the TA564-11 is widely used in PLC cabinets, machine control systems, and process automation equipment where stable and organized wiring is essential.
Technical Specifications
Parameter
Specification
Model
TA564-11
Product ID
1TNE968901R3104
Manufacturer
ABB
Module Type
Terminal Block
Series
AC500-eCo / S500-eCo
Connection Type
Screw Front, Cable Front
Pole Configuration
11-pole
Mounting Method
Panel / DIN rail system integration
Protection Rating
IP20
Operating Temperature
−25°C to +70°C
Dimensions (L × W × H)
40 × 150 × 250 mm
Weight
0.036 kg
The TA564-11 terminal block is designed for reliable wiring connections within ABB PLC systems, supporting efficient installation and maintenance.
Recommended Related Models
Model
Description
TA563-11
11-pole terminal block with screw front and side cable connection
TA564-9
9-pole terminal block with front cable connection
TA565-11
11-pole terminal block with spring front terminals
TA565-9
9-pole spring terminal block
TA562-RS
RS485 serial communication adapter for AC500
These accessories are often used together to provide flexible wiring solutions for ABB AC500 PLC installations.
Popular ABB Models
Model
Module Type
PM590-ETH
PLC CPU Controller
CI840A
Communication Interface Module
AI830A
Analog Input Module
SB822
Redundant Power Supply Module
PP865A
Operator Panel
These ABB products are widely used in industrial automation and distributed control systems worldwide.
Applications
The ABB TA564-11 Terminal Block is designed for structured and secure wiring in PLC-based control systems.
Typical applications include:
PLC control cabinet wiring
Machine automation systems
Industrial manufacturing lines
Process control installations
Water treatment automation
Energy and utility control systems
Factory equipment control panels
By simplifying field wiring and improving electrical connection reliability, the TA564-11 contributes to safer and more maintainable automation systems.
Advantages
Efficient PLC Wiring Interface
Provides a clear and structured connection point between PLC modules and field devices.
Front-Access Screw Terminals
Front-screw wiring simplifies installation and maintenance in compact control cabinets.
Reliable Electrical Connection
Secure screw terminals ensure stable signal transmission.
Easy System Integration
Fully compatible with ABB AC500-eCo PLC and S500-eCo I/O modules.
Industrial Durability
Built to withstand vibration, temperature changes, and electrical noise in industrial environments.
Technical FAQs
1. What is the ABB TA564-11 used for?
It is a terminal block used to connect field wiring to ABB AC500-eCo PLC and S500-eCo I/O modules.
2. How many terminals does the module have?
The TA564-11 features an 11-pole terminal configuration.
3. What type of wiring connection does it use?
It uses front screw terminals with front cable entry for convenient wiring.
4. Which PLC systems support this terminal block?
It is designed primarily for ABB AC500-eCo PLC systems.
5. What is the protection rating of the module?
The terminal block provides IP20 protection for industrial cabinet installations.
6. What are the dimensions of the TA564-11?
Its dimensions are 40 × 150 × 250 mm.
7. What is the weight of the module?
The module weighs approximately 0.036 kg.
8. Is DIN-rail installation supported?
Yes, it can be integrated into standard control panel installations with DIN-rail-based PLC systems.
9. What industries commonly use this module?
Manufacturing, energy, process industries, and machine automation commonly use it.
10. Why choose ABB terminal blocks for PLC systems?
ABB accessories offer reliable electrical connections, long service life, and seamless compatibility with ABB automation platforms.
