ABB TB5610-2ETH Ethernet Terminal Base Module for AC500 V3 PLC Systems
ABB TB5610-2ETH Ethernet Terminal Base Module for AC500 V3 PLC Systems
0.0
Points
Brand:ABB PLC Item No.:ABB TB5610-2ETH Product Origin:Sweden Product Dimensions:135 × 95.5 × 28 mm Product Weight:0.157 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB TB5610-2ETH is a high-performance terminal base designed for the AC500 V3 PLC platform, providing reliable connectivity and stable system expansion for industrial automation environments. It acts as the physical interface for processor modules while enabling flexible communication through integrated Ethernet and field interfaces.
Engineered for modern control architectures, this terminal base integrates dual Ethernet interfaces, serial communication, and CAN connectivity, allowing seamless data exchange between PLC systems, field devices, and supervisory control platforms.
Its compact design, DIN-rail mounting capability, and robust electrical protection make it an ideal choice for manufacturing automation, energy systems, and process control installations where stability and communication performance are critical.
Technical Specifications
Parameter
Specification
Product Model
TB5610-2ETH
Product Type
Ethernet Terminal Base Module
Compatible Platform
AC500 V3 PLC
Communication Interfaces
2 × Ethernet (RJ45), 1 × Serial Interface, 1 × CAN Interface
Communication Module Slot
1 Slot
Input Voltage Type
DC
Protection Class
IP20
Mounting Method
DIN Rail Mount
Operating Temperature
-20°C to +60°C
Storage Temperature
-40°C to +85°C
Relative Humidity
5% – 95% (non-condensing)
Data Transmission Rate
10/100 Mbps
Supported Protocols
TCP/IP, UDP, DHCP, ARP
Ethernet Standard
IEEE 802.3 (10BASE-T, 100BASE-TX)
Maximum Ethernet Cable Length
100 m per segment
Dimensions
135 × 95.5 × 28 mm
Weight
0.157 kg
Recommended Related Models
The following modules are commonly paired with the TB5610-2ETH to build scalable AC500 automation systems:
ABB PM5630 Processor Module
ABB PM5650 High-Performance CPU Module
ABB PM5670 Advanced PLC Processor
ABB CM582-DP PROFIBUS Communication Module
ABB CM589-PNIO PROFINET Interface Module
These components allow system designers to expand communication capability, integrate additional fieldbus networks, and enhance processing performance.
Popular ABB Automation Models
Several ABB PLC and automation modules are widely used across industrial control systems:
ABB PM590-ETH PLC CPU
ABB PM591-2ETH Controller Module
ABB CI801 Communication Interface
ABB AI830A Analog Input Module
ABB SB822 Power Supply Module
These devices form reliable control platforms used in distributed automation environments.
Industrial Applications
The TB5610-2ETH terminal base is designed to support demanding automation tasks in various industries:
Manufacturing automation systems
Power generation and energy management
Process control plants
Water and wastewater treatment facilities
Oil and gas control systems
Smart factory and digital production lines
Its robust networking capabilities ensure stable data communication between PLC controllers, SCADA systems, and field devices.
Key Advantages
Reliable Industrial Communication
Dual Ethernet ports enable redundant network connections and stable high-speed communication for PLC systems.
Flexible System Expansion
The integrated communication module slot allows easy integration of additional fieldbus or industrial network modules.
Compact Installation
A slim DIN-rail design ensures efficient cabinet space utilization while simplifying system wiring.
Industrial-Grade Durability
Designed to operate in harsh environments with wide temperature tolerance and high insulation protection.
Optimized for AC500 Architecture
Seamlessly integrates with ABB AC500 V3 PLC processors to build scalable and high-performance automation platforms.
Technical FAQs
1. What is the main function of the TB5610-2ETH module?
It serves as the terminal base for AC500 V3 processor modules, providing power distribution, physical connections, and communication interfaces.
2. How many Ethernet ports does the module provide?
The module includes two RJ45 Ethernet interfaces for industrial network connectivity.
3. Does the TB5610-2ETH support additional communication modules?
Yes. It provides one slot for optional communication modules such as PROFIBUS, CANopen, or PROFINET.
4. What PLC platform is compatible with this module?
It is specifically designed for ABB AC500 V3 PLC systems.
5. What is the mounting method for this module?
The module is installed on a standard DIN rail inside industrial control cabinets.
6. What communication protocols are supported through Ethernet?
Typical supported protocols include TCP/IP, UDP, DHCP, and ARP.
7. What protection rating does the module have?
The module is rated IP20, suitable for installation inside control cabinets.
8. What is the operating temperature range?
It operates reliably between -20°C and +60°C.
9. What are the physical dimensions of the TB5610-2ETH?
The module measures 135 × 95.5 × 28 mm.
10. What is the approximate weight of the unit?
The product has a net weight of approximately 0.157 kg, making it lightweight and easy to integrate into PLC racks.
