The ABB TK801V006 is a ModuleBus extension cable specifically designed for ABB S800 I/O distributed control systems. It enables engineers to extend the communication path between I/O modules while maintaining stable ModuleBus connectivity within industrial automation architectures.
This prefabricated shielded cable provides a 0.6-meter connection length, making it ideal for linking modules installed on separate DIN rails within the same control cabinet. By extending the ModuleBus connection, the cable allows greater flexibility when designing cabinet layouts in complex automation environments.
The cable uses D-Sub 25-pin male-to-female connectors, ensuring secure communication between S800 I/O components such as bus outlet modules and bus inlet adapters. Its industrial shielding protects communication signals from electromagnetic interference, ensuring reliable operation in demanding industrial settings.
With its compact size, durable construction, and easy installation, the TK801V006 provides a dependable connectivity solution for engineers building scalable ABB control systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | TK801V006 |
| Product ID | 3BSC950089R2 |
| Product Type | ModuleBus Extension Cable |
| System Compatibility | ABB S800 I/O / System 800xA / Freelance DCS |
| Communication Protocol | ModuleBus |
| Cable Type | Shielded Prefabricated Cable |
| Cable Length | 0.6 m |
| Connector Type | D-Sub 25 (Male–Female) |
| Installation | DIN-Rail I/O Cabinet Integration |
| EMI Protection | Shielded Industrial Cable |
| Dimensions | 89 × 76 × 58 mm |
| Weight | 0.19 kg |
The cable is designed to extend ModuleBus communication so that I/O modules on the same electrical bus can be installed across multiple DIN rails within a control cabinet.
Recommended Related Models
The TK801V006 cable is commonly used with the following ModuleBus accessories:
-
ABB TB805 ModuleBus Outlet Adapter
-
ABB TB845 Dual ModuleBus Outlet
-
ABB TB806 ModuleBus Inlet Adapter
-
ABB TB846 Dual ModuleBus Inlet
-
ABB TK801V003 ModuleBus Extension Cable (0.3 m)
-
ABB TK801V012 ModuleBus Extension Cable (1.2 m)
These components help engineers build flexible and scalable S800 I/O architectures.
