The ABB TU836V1 Module Termination Unit (MTU) is engineered for ABB S800 I/O distributed automation systems, providing a dependable interface between field wiring and I/O modules. Designed to deliver precise signal routing and robust communication distribution, this unit supports structured wiring and simplifies cabinet installation for industrial control architectures.

Featuring a modular layout and industry–grade components, the TU836V1 supports up to 12 I/O signal connections, making it ideal for mid‑range automation applications where compactness and reliability are essential. Integrated ModuleBus communication distribution ensures stable data transfer between connected modules and system controllers. Its mechanical keying system prevents incorrect module placement, safeguarding system integrity and reducing commissioning errors.

This termination unit is widely used in complex process automation, manufacturing, and energy applications where high uptime and controlled signal integrity are paramount.

Technical Specifications

Parameter	Specification
Model	TU836V1
ABB Article Number	3BSE013237R1
Product Type	Module Termination Unit (MTU)
System Compatibility	ABB S800 I/O
Signal Channels	Up to 12
Rated Voltage	50 V
Maximum Current per Channel	2 A
Process Connections	40
Connection Type	Terminal block
Mounting	DIN rail (horizontal or vertical)
Protection Class	IP20
Operating Temperature	0 °C to +55 °C
Storage Temperature	−40 °C to +70 °C
Dimensions (H × W × D)	110 × 126 × 64 mm
Weight	0.27 kg

The TU836V1 helps distribute ModuleBus signals and organize field wiring efficiently, making it suitable for distributed control systems where space and wiring clarity are important.

Recommended Related Models

Model	Description
TU810V1	Compact MTU for foundational S800 I/O installations
TU811V1	8‑channel termination unit
TU812V1	16‑channel MTU with D‑Sub interface
TU814V1	Snap‑in connector MTU for versatile wiring
TU830V1	Extended MTU with dual power groups
TU835V1	Mid‑range MTU with 8 channels

Popular ABB Automation Modules

Model	Module Type
PM803F	Controller CPU Module
CI840A	Communication Interface Module
AI830A	Analog Input Module
SB822	Power Supply Module
PP865A	Operator Panel
PM583‑ETH	PLC CPU with Ethernet Connectivity

Typical Industrial Applications

The ABB TU836V1 is commonly deployed in industrial automation environments where reliable field termination and communication distribution are essential:

Distributed Control Systems (DCS)
Process automation in chemical, pharmaceutical, and petrochemical plants
Power generation and utilities control rooms
Oil and gas automation networks
Manufacturing production lines
Water and wastewater treatment automation

Its modular design and compact footprint make the TU836V1 suitable for control cabinets with medium‑density I/O requirements.

Key Advantages

Reliable Signal Management
Supports up to 12 I/O signal connections with structured wiring for enhanced system reliability.

Integrated ModuleBus Communication
Ensures stable data transfer between modules and controllers in distributed system architectures.

Mechanical Keying Protection
Prevents incorrect module installation, reducing configuration errors and downtime.

Compact DIN‑Rail Mounting
Fits efficiently in control cabinets where space is at a premium.

Industrial‑Grade Durability
Built to withstand typical automation environmental conditions.

Technical FAQs

1. What is the purpose of the ABB TU836V1?
It is a module termination unit that connects field wiring to ABB S800 I/O modules and distributes ModuleBus signals.

2. How many I/O channels does the TU836V1 support?
It supports up to 12 channels.

3. Which systems is it compatible with?
It is designed for ABB S800 I/O distributed control systems.

4. What is the rated voltage for this unit?
The rated voltage is 50 V.

5. What is the maximum current per channel?
Up to 2 A per channel.

6. What type of connections does it use?
Terminal block connections are used for field wiring.

7. How is the unit mounted?
It is mounted on a DIN rail, supporting horizontal or vertical installation.

8. Does it provide ModuleBus distribution?
Yes, it distributes communication signals between modules.

9. Is it suitable for medium‑density I/O applications?
Yes — the 12‑channel support fits mid‑range automation cabinets.

10. Why choose ABB TU836V1 in automation systems?
Because it delivers compact installation, reliable signal termination, and seamless integration within ABB S800 I/O architectures.
