The ABB UF C721 AE101 is a robust voltage and current measurement module with integrated communication interface for advanced industrial automation systems. It enables precise real-time acquisition of voltage and current signals and seamless communication with controllers, making it ideal for distributed control systems, drive systems, and process automation platforms.
This module ensures industrial-grade reliability, delivering consistent performance in harsh electrical environments, and integrates easily into control cabinets and I/O racks thanks to its compact and modular design.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | UF C721 AE101 |
| ABB Article Number | 3BHB002916R0101 |
| Product Type | Voltage/Current Measurement and Communication Module |
| Function | Analog voltage/current acquisition and communication interface |
| System Compatibility | ABB Advant OCS, S800 I/O systems |
| Power Supply | 24 V DC via backplane or field supply |
| Operating Temperature | -25 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% – 95% (non-condensing) |
| Isolation | 1500 V AC typical |
| EMC Compliance | Industrial standard |
| Dimensions (L × W × H) | 120 × 80 × 30 mm |
| Weight | 0.81 kg |
| Protection Rating | IP20 (installation dependent) |
Recommended Related Modules
| Model | Description |
|---|---|
| UF C719 AE01 | I/O control board (IOEC) interface module |
| UF C722 AE | Companion analog/digital measurement module |
| CI801 | Communication interface module |
| PM803F | Controller CPU module |
| AI830A | Analog input module |
