ABB XC08L1 Digital I/O Extension Module for Industrial Control Systems
ABB XC08L1 Digital I/O Extension Module for Industrial Control Systems
0.0
Points
Brand:ABB PLC Item No.:ABB XC08L1 Product Origin:Sweden Product Dimensions:102 × 76 × 102 mm Product Weight:0.20 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB XC08L1 (part number 1SBP260102R1001) is an industrial Digital I/O Extension Unit engineered to expand digital input/output capacity within ABB automation installations. It provides a compact and robust way to add additional digital channels to PLC or distributed control system architectures, helping factories and plants scale control interfaces without major redesign.
Designed to operate on a 24 V DC supply, this extension module seamlessly integrates with existing ABB controllers, enabling reliable monitoring and actuation of digital signals. Its flexible, configurable I/O channels support both input and output roles, making it suitable for a wide range of industrial applications where dependable signal handling is crucial.
Technical Specifications
Parameter
Specification
Model
XC08L1
ABB Article Number
1SBP260102R1001
Product Type
Digital I/O Extension Module
Manufacturer
ABB
Number of Configurable I/O
8 Inputs & 8 Outputs (configurable)
Digital Input Voltage
0–24 V DC
Digital Input Current
5 mA per input
Digital Output Voltage
24 V DC
Digital Output Current
0.5 A per output
Power Supply
24 V DC
Operating Temperature
-20 °C to +60 °C
Dimensions (L × W × H)
102 × 76 × 102 mm (10.2 cm × 7.6 cm × 10.2 cm)
Weight
0.20 kg
Protection Rating
Industrial enclosure (dependent on installation)
The compact form factor makes the XC08L1 ideal for space‑constrained control panels and distributed automation racks.
Recommended Related Models
Model
Description
Abb XC08L1-D4.0
Alternative I/O extension variant
Abb Xc08L1 Configurable I/O Extension Module
I/O expansion for 8×24 V DC control
Abb Xc08L1-d4.0 Extension Module
Digital I/O extension with similar specs
DI16E1
16‑channel digital input expansion module
XO16R1
16‑channel digital output module
Popular ABB Automation Modules
Model
Module Type
PM803F
PLC Controller CPU
AI830A
Analog Input Module
CI801
Communication Interface Module
SB822
Power Supply Module
PP865A
Operator Panel / HMI
PM583‑ETH
Ethernet‑Enabled PLC Controller
Typical Applications
The ABB XC08L1 Digital I/O Extension Module is widely used in industrial automation scenarios where scalable digital I/O is required:
PLC system expansion for additional I/O capacity
Machine control panels and local automation nodes
Digital signal acquisition for sensors and switches
Actuator control in manufacturing processes
Building and facility automation interfaces
Distributed control architectures requiring modular I/O expansion
Its balance of compact design and high reliability makes it a flexible component for both new installations and retrofit upgrades.
Key Advantages
Flexible Configurable I/O
Supports both digital inputs and outputs on the same module for flexible system design.
Robust Industrial Design
Built for reliable performance in standard industrial environments with a broad temperature range.
Compact Footprint
At 102 × 76 × 102 mm and only 0.20 kg, it fits easily in crowded control cabinets.
Easy Integration
Integrates seamlessly with ABB PLC and DCS platforms, enhancing scalability without complex rewiring.
Stable 24 V DC Operation
Designed to operate on common industrial control voltage, simplifying power distribution.
Technical FAQs
1. What is the ABB XC08L1 used for?
It is a digital I/O extension module used to add configurable inputs and outputs to ABB control systems.
2. How many I/O channels does it have?
It supports 8 configurable digital inputs and 8 outputs on a single board.
3. What voltage does it operate at?
It operates at 24 V DC.
4. What is the input current requirement?
Inputs are rated at 5 mA @ 0–24 V DC.
5. What is the output current rating?
Each digital output supports up to 0.5 A.
6. How big is the module? 102 × 76 × 102 mm (L × W × H).
7. How much does it weigh?
It weighs about 0.20 kg.
8. Can it integrate with PLC systems?
Yes — it expands digital I/O on compatible ABB PLC and DCS platforms.
9. Is this module suitable for harsh environments?
It is designed for industrial environments with standard temperature tolerances.
10. Why choose the XC08L1 module?
Because it provides flexible, compact, and reliable digital I/O expansion for industrial automation systems.
