ABB YPI103E 16-Channel Digital Input Module for Symphony Plus and Industrial Automation Control Systems
ABB YPI103E 16-Channel Digital Input Module for Symphony Plus and Industrial Automation Control Systems
0.0
Points
Brand:ABB PLC Item No.:ABB YPI103E Product Origin:Sweden Product Dimensions:120 × 80 × 40 mm Product Weight:0.5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB YPI103E (part number YT204001-FB) is a high-performance Digital Input Module engineered for reliable signal acquisition in advanced industrial automation and distributed control systems. Designed for ABB control architectures such as Symphony Plus, this module captures discrete signals from field devices and converts them into precise digital data for monitoring and control operations.
With 16 isolated digital input channels, the YPI103E enables efficient monitoring of equipment such as push buttons, limit switches, proximity sensors, and other field instruments. Each channel includes LED indicators for clear operational feedback, ensuring engineers can quickly diagnose system status during commissioning or maintenance.
Its rugged industrial design, compact size, and strong electrical isolation make it ideal for applications where stable signal integrity and dependable control system integration are critical.
Technical Specifications
Parameter
Specification
Model
YPI103E
ABB Part Number
YT204001-FB
Product Type
Digital Input Module
Input Channels
16 isolated digital inputs
Input Voltage
24 V DC
Input Current
5 mA per channel
Signal Type
Sink / source configurable
Status Indicators
LED indicator for each channel
Mounting Type
DIN rail
Operating Temperature
-20°C to +60°C
Storage Temperature
-40°C to +85°C
Communication / Integration
Compatible with ABB DCS / automation systems
Protection
Channel-to-channel and channel-to-bus isolation
Dimensions (L × W × H)
120 × 80 × 40 mm
Weight
0.5 kg
The module is optimized for reliable digital signal acquisition and stable integration into modern industrial automation environments.
Recommended Related Models
Model
Description
ABB YPH105E
Digital speed input module
ABB YPG109A
Analog input connection module
ABB YPM106E
Analog output interface module
ABB YPO105E
Digital output module
ABB YPK109E
Communication interface module
Popular ABB Automation Modules
Model
Module Type
ABB PM803F
Controller CPU Module
ABB CI801
Communication Interface Module
ABB AI830A
Analog Input Module
ABB SB822
Power Supply Module
ABB PP865A
Operator Panel (HMI)
ABB PM583-ETH
PLC Controller with Ethernet
Applications
The ABB YPI103E Digital Input Module is widely used in automation systems requiring dependable digital signal monitoring.
Typical applications include:
Distributed control systems (DCS) in power plants and process industries
Industrial machinery monitoring and control
Factory automation and manufacturing lines
Sensor and switch signal acquisition
Equipment status monitoring systems
Safety and interlock systems
By collecting real-time digital signals from field devices, the module ensures reliable feedback for supervisory control systems.
Advantages
High-Reliability Signal Acquisition
Sixteen isolated digital channels provide accurate and stable input signal monitoring.
Clear Status Diagnostics
Integrated LED indicators allow engineers to instantly view channel status.
Industrial-Grade Isolation
Channel-to-channel electrical isolation improves system safety and signal integrity.
Compact Panel Integration
With dimensions of 120 × 80 × 40 mm, the module fits easily inside standard control cabinets.
Easy Installation
DIN-rail mounting and removable terminal blocks simplify installation and maintenance.
Technical FAQs
1. What is the ABB YPI103E used for?
It is a digital input module designed to collect discrete signals from field devices in industrial automation systems.
2. How many input channels does it support?
The module provides 16 isolated digital input channels.
3. What input voltage does the module use?
It operates with 24 V DC input signals.
4. What are the module dimensions?
The physical size is 120 × 80 × 40 mm.
5. What is the module weight?
The approximate weight is 0.5 kg.
6. Does it provide channel isolation?
Yes, the module offers channel-to-channel and channel-to-bus isolation for improved safety and signal integrity.
7. How is the module installed?
It is typically installed on a DIN rail inside a control cabinet.
8. What devices connect to this module?
Common devices include push buttons, proximity sensors, limit switches, and digital field instruments.
9. What environments is it designed for?
It is designed for industrial environments with operating temperatures from −20°C to +60°C.
10. Why choose ABB YPI103E?
Because it provides high-reliability digital signal monitoring, strong electrical isolation, and seamless integration with ABB control systems.
