The GE IS220PRTDH1B is a Turbine Remote Trip and Display Module designed for the Mark VIe and Mark VIeS control systems. It delivers high-speed remote turbine trip outputs while providing real-time status displays for turbine operation. This dual-function module ensures that operators can both monitor and protect turbines efficiently, combining safety and visibility in one compact unit.
The IS220PRTDH1B is engineered for industrial-grade reliability, supporting redundant architectures and hot-swappable integration. Its fast response and diagnostic capabilities make it essential for power generation facilities, industrial turbines, and other mission-critical applications where turbine safety cannot be compromised.
Technical Specifications
Parameter
Specification
Model
IS220PRTDH1B
Module Type
Turbine Remote Trip & Display Module
System Compatibility
Mark VIe / Mark VIeS
Output Channels
16 channels (isolated)
Display Outputs
Status LEDs / Analog indicators
Output Voltage Range
0–32 V DC / 115–230 V AC
Trip Response Time
< 5 ms typical
Power Supply
28 V DC nominal
Power Consumption
≤ 15 W
Communication Interface
Dual Ethernet (IONet)
Redundancy Capability
TMR (Triple Modular Redundant) support
Mounting
Terminal board integration
Operating Temperature
-20°C to +70°C
Dimensions (L×W×H)
160 × 160 × 120 mm
Weight
0.8 kg
Recommended Related Models
IS220PPROH1A – Turbine Protection Output Module
IS220PPROS1B – Turbine Protection Output Signal Module
The IS220PRTDH1B is designed for remote turbine trip and monitoring applications, including:
Emergency turbine trip and overspeed protection
Real-time turbine status visualization
Power generation plants and combined-cycle facilities
Industrial turbine monitoring systems
Backup protection for mission-critical turbines
It provides fast, reliable trip signaling while giving operators real-time feedback, improving both safety and operational awareness.
Key Advantages
Dual Functionality – Combines emergency trip outputs with real-time status display
Fast Response – Trip signal response time under 5 ms
Redundant and Reliable – Supports TMR configurations for fail-safe operation
Dual Ethernet Interface – Facilitates integration and diagnostics
Robust Industrial Construction – Performs reliably in harsh environments
Onboard Diagnostics – LED indicators and status feedback simplify troubleshooting
Technical FAQs
1. What is the main purpose of IS220PRTDH1B?
It provides remote turbine trip capability along with real-time display of turbine status.
2. How many output channels are available?
16 isolated output channels.
3. What types of display outputs are included?
Status LEDs and optional analog indicators.
4. What is the typical trip response time?
Less than 5 milliseconds.
5. Can it operate independently of the main controller?
Yes, it can function as an independent module within redundant systems.
6. Does it support TMR architectures?
Yes, it is compatible with triple modular redundant systems.
7. What communication interface does it use?
Dual Ethernet (IONet) for control, monitoring, and diagnostics.
8. Which industries typically use this module?
Power generation, industrial turbines, and oil & gas facilities.
9. What is the operating temperature range?
-20°C to +70°C, suitable for industrial environments.
10. Why choose IS220PRTDH1B?
Because it ensures rapid turbine trip response, reliable monitoring, and industrial-grade durability in mission-critical applications.
