Schneider ATV320U15N4B Altivar Machine ATV320 Series 1.5kW Book-Style Variable Frequency Drive for Space-Saving Industrial Motor Control Solutions
Schneider ATV320U15N4B Altivar Machine ATV320 Series 1.5kW Book-Style Variable Frequency Drive for Space-Saving Industrial Motor Control Solutions
0.0
Points
Brand:Schneider PLC Item No.:Schneider ATV320U15N4B Product Origin:France Product Dimensions:230 × 45 × 270 mm Product Weight:2.33 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV320U15N4B is a compact and high-efficiency variable frequency drive from the Altivar Machine ATV320 series, designed specifically for OEM machine builders and industrial automation systems. Featuring a slim book-style design, this drive is ideal for installations where panel space is limited but performance cannot be compromised.
Engineered for both asynchronous and synchronous motors, it delivers precise speed regulation, strong torque performance, and excellent energy efficiency. With integrated safety features and flexible communication capabilities, the ATV320U15N4B ensures reliable operation across a wide range of industrial environments.
Technical Specifications
Parameter
Specification
Model
ATV320U15N4B
Product Type
Variable Frequency Drive (VFD)
Series
Altivar Machine ATV320
Rated Power
1.5 kW (2 HP)
Input Voltage
380–500 V AC (3-phase)
Rated Output Current
4.1 A
Output Frequency
0.1 – 599 Hz
Control Method
Sensorless Vector Control
Communication
Modbus, CANopen (expandable)
Form Factor
Book-style
Protection Rating
IP20
EMC Filter
Integrated Class C2
Operating Temperature
-10°C to +60°C
Dimensions (H × W × D)
230 × 45 × 270 mm
Weight
2.33 kg
Mounting Type
Panel / Cabinet Mount
Recommended Related Models
ATV320U11N4B – 1.1 kW version for lighter applications
ATV320U22N4B – 2.2 kW model for higher load demands
ATV320U15N4C – Compact version with expanded I/O
ATV320D15N4C – Chassis-type drive for enhanced integration
ATV340U15N4 – Advanced drive for high dynamic performance
Popular Schneider Electric Models
Altivar 320 Series Drives
Altivar 340 High-Performance Drives
Altivar 630 Process Drives
Modicon M241 / M251 PLC
Lexium Servo Systems
Applications
The ATV320U15N4B is widely used in compact and performance-driven automation systems:
Conveyor and material handling equipment
Packaging and labeling machines
Pumps, fans, and HVAC systems
Textile and ceramic machinery
Food processing lines
OEM modular machinery
Advantages
Ultra-Slim Book Design: Maximizes cabinet space utilization in dense installations
Reliable Motor Control: Ensures stable torque and precise speed regulation under varying loads
Integrated EMC Filter: Simplifies installation and enhances electromagnetic compatibility
Flexible Communication: Supports industrial networking via expansion modules
Advanced Safety Features: Includes functions like Safe Torque Off (STO) for enhanced protection
Energy Efficient: Optimizes motor performance to reduce operational costs
Technical FAQs
1. What motor power does this drive support?
It supports motors up to 1.5 kW (2 HP).
2. What is the input voltage range?
380–500 V AC, three-phase.
3. What is the rated output current?
Approximately 4.1 A under heavy-duty conditions.
4. Does it support industrial communication protocols?
Yes, Modbus and CANopen are supported, with expansion options available.
5. What makes the book-style design advantageous?
It allows vertical installation, saving significant panel space.
6. Can it control different motor types?
Yes, both synchronous and asynchronous motors are supported.
7. Is an EMC filter included?
Yes, a Class C2 EMC filter is integrated.
8. What is the maximum output frequency?
Up to approximately 599 Hz.
9. What industries commonly use this model?
Packaging, material handling, HVAC, and general automation industries.
10. Is it suitable for OEM applications?
Yes, it is specifically designed for machine builders and modular systems.
