The Schneider HMIPSPS752D1X01 is a high-performance industrial power supply module designed for modular PLC systems, including Modicon and Premium series automation platforms. Delivering 24 V DC at 7.5 A, this module ensures stable and reliable power to I/O modules, controllers, and field devices. Engineered for industrial durability, it offers short-circuit protection, thermal monitoring, and compact dimensions, making it ideal for control cabinets, automation panels, and process control applications.
Technical Specifications
| Feature | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | HMIPSPS752D1X01 |
| Module Type | Industrial Power Supply Module |
| Output Voltage | 24 V DC |
| Output Current | 7.5 A |
| Rated Power | 180 W |
| Input Voltage | 100–240 V AC, 50/60 Hz |
| Efficiency | >90 % |
| Protection Features | Short-circuit, overload, overvoltage, thermal shutdown |
| Status Indicators | Output OK, Fault LED |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –25 °C to +70 °C |
| Shock Resistance | 30 gn |
| Vibration Resistance | 3 gn |
| Protection Rating | IP20 |
| Dimensions (L × W × H, mm) | 120 × 90 × 70 mm |
| Weight | ~400 g |
