The Schneider TSXCFY11 is a dedicated Motion Control Module engineered for precise control of stepper motor drives within the Modicon Premium automation platform. Designed to seamlessly integrate with Premium PLC systems, this module provides reliable single‑axis motion management with industry‑proven performance. Its compact design and efficient power usage make it ideal for applications where accurate positioning and smooth velocity profiles are essential. The TSXCFY11 is a go‑to solution for automation specialists seeking robust motion control in legacy and retrofit environments.
Technical Specifications
| Specification | Detail |
|---|---|
| Model | TSXCFY11 |
| Module Type | Motion Control Module |
| Platform Compatibility | Modicon Premium Automation |
| Application | Stepper motor motion control (1 axis) |
| Control Software Support | Unity Pro |
| Maximum Pulse Frequency | ~187 kHz |
| Power Dissipation | 3.8 W |
| Input Type | Current sink auxiliary inputs (EN/IEC 61131 type 2) |
| Electrical Connections | HE‑10 (20 pins) + SUB‑D (15 pins) |
| Current Consumption | ~510 mA @ 5 V DC |
| Operating Temp. | 0 °C to 60 °C |
| Storage Temp. | -25 °C to 70 °C |
| Humidity | 5 %–95 % (non‑condensing) |
| Dimensions (Approx. L×W×H) | 200 mm × 151.5 mm × 50 mm (industry module size estimate) |
| Weight (Approx.) | 0.44 kg |
| Discontinuation | Product discontinued; end‑of‑service scheduled by 2026 |
Recommended Related Models
| Model | Why It’s Recommended |
|---|---|
| Schneider TSXCFY21 | Dual‑axis motion module for expanded motion control |
| Schneider TSXCAY21 | Analog motion control for servomotors |
| Schneider TSXCSY84 | Servo motion control via SERCOS interface |
| Schneider TSXCCY1128 | High‑frequency motion module for advanced profiles |
Popular Schneider Models
| Model | Key Strength |
|---|---|
| Schneider Modicon M241 | Mid‑range PLC with integrated networking |
| Schneider Modicon M221 | Compact controller for small automation |
| Schneider Modicon M580 | High‑speed PAC for enterprise systems |
| Schneider Modicon Quantum I/O | Scalable I/O platform for large machines |
Applications
The TSXCFY11 excels in motion‑centric roles within industrial automation:
- Precision control of stepper motors in packaging lines
- CNC and indexing table positioning systems
- Material handling actuators requiring repeatable motion
- Vision‑guided assembly and pick‑and‑place operations
- Retrofits of legacy Modicon motion installations
