The GE IC695ALG112 is a high-performance analog input module designed for the PACSystems RX3i platform, delivering precise and reliable acquisition of industrial analog signals. It is engineered to interface directly with field instruments such as pressure transmitters, flow meters, temperature sensors, and level devices.
With high-resolution conversion and channel isolation, this module ensures accurate signal processing even in electrically noisy environments. It is widely deployed in process automation, energy systems, and high-precision manufacturing, where stable and real-time analog data is critical for control decisions.
Built for flexibility and performance, the IC695ALG112 supports a wide range of input signal types, making it a versatile solution for modern PLC architectures.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | GE (Emerson Automation) |
| Model | IC695ALG112 |
| Product Type | Analog Input Module |
| Series | PACSystems RX3i |
| Input Channels | 12 isolated channels |
| Input Signal Types | Voltage & Current |
| Voltage Range | ±10 V, 0–10 V, ±5 V, 0–5 V, 1–5 V |
| Current Range | 0–20 mA, 4–20 mA, ±20 mA |
| Resolution | 16-bit ADC |
| Accuracy | ~0.1% (typical at 25°C) |
| Input Impedance | >500 kΩ (voltage) |
| Isolation | Channel-to-channel isolation |
| Conversion Type | Floating point / integer |
| Filter Options | 8 / 12 / 16 / 40 / 250 / 1000 Hz |
| Overvoltage Protection | ±35 VDC continuous |
| Power Consumption | ~4.9 W (max) |
| Backplane Power | 3.3 V & 5 V supply |
| Mounting | RX3i universal backplane |
Physical Dimensions (L × W × H)
| Item | Value |
|---|---|
| Size | 263 × 58 × 28 mm |
| Weight | ~4.3 kg |
The 263 × 58 × 28 mm design ensures efficient rack utilization, while the robust build supports stable operation in industrial control cabinets.
Recommended Related Models
- GE IC695ALG600 – Universal analog input module
- GE IC695ALG120 – Compact analog input module
- GE IC695ALG220 – Advanced high-density analog module
- GE IC695CMM002 – Serial communication module
- GE IC695CPU310 – RX3i CPU module
Popular GE RX3i Analog & Control Modules
- RX3i CPU controllers (CPE / CPU series)
- Analog input/output modules (ALG series)
- Digital I/O modules (MDL series)
- Communication modules (CMM / ENET series)
- Power and backup modules (PWR / ACC series)
These modules are widely used in process industries, utilities, manufacturing automation, and energy management systems.
