The GE IC695CMX128 is a Control Memory Xchange (CMX) module designed for the PACSystems RX3i platform, built to enable high-speed deterministic data sharing between controllers and distributed automation systems.
It uses reflective memory technology over fiber optic communication, allowing multiple PLCs and computing nodes to share a common memory space in real time. When one device writes data to memory, all connected nodes receive the update instantly without CPU intervention.
With 128 MB shared SDRAM, this module is widely used in synchronized multi-controller systems, motion control networks, and high-speed industrial automation architectures where latency-free data exchange is essential.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | GE (Emerson Automation / GE Fanuc legacy) |
| Model | IC695CMX128 |
| Product Type | Control Memory Xchange (CMX) Module |
| Series | PACSystems RX3i |
| Memory Size | 128 MB SDRAM shared memory |
| Network Type | Reflective memory (fiber optic) |
| Data Transfer Rate | Up to 2.1 Gbps |
| Node Capacity | Up to 256 nodes |
| Packet Size | Dynamic (4–64 bytes) |
| Power Consumption | 3.3V: 660 mA / 5V: 253 mA |
| Interface | Dual fiber optic LC connectors |
| Fiber Standard | IEC 61754-20 |
| Redundancy Support | Yes (multi-node synchronization) |
| Hot Swap | Supported |
| Diagnostics | Network integrity & error detection |
The module is designed for deterministic, real-time data synchronization, eliminating traditional network delays in PLC communication systems.
Physical Dimensions (L × W × H)
| Item | Value |
|---|---|
| Size | 147 × 51 × 112 mm |
| Weight | ~0.22 – 0.80 kg |
The compact 147 × 51 × 112 mm design allows installation into RX3i racks without occupying excessive space, while maintaining high-speed fiber optic communication performance.
