The GE IC697ACC702A is an I/O Bus Terminator Plug designed for GE Fanuc Series 90-70 PLC systems. It is a small but essential component used to terminate the I/O expansion bus at the final node of a daisy-chain configuration, ensuring clean signal transmission and preventing data reflection or communication errors.
In distributed PLC architectures, this terminator plays a critical role in maintaining signal integrity, system stability, and reliable module communication, especially in long or multi-rack expansions.
Technical Specifications
The IC697ACC702A is engineered as a passive termination component for GE industrial control networks.
| Parameter | Specification |
|---|---|
| Model | IC697ACC702A |
| Product Type | I/O Bus Terminator Plug |
| System Compatibility | GE Fanuc Series 90-70 |
| Function | Bus signal termination |
| Installation Position | Last I/O expansion rack / BRM module |
| Electrical Type | Passive resistor termination |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | Approx. 70 mm × 51 mm × 19 mm |
| Weight | Approx. 45 g – 60 g |
The compact design allows direct installation into the expansion port of the last bus receiver module without additional wiring or configuration complexity.
Recommended Related Models
For complete Series 90-70 system integration, the following components are commonly used alongside IC697ACC702A:
- GE IC697BEM713 Bus Transmitter Module
- GE IC697BEM711 Bus Receiver Module
- GE IC697CPU772 PLC Processor Module
- GE IC697CHS790 Rack Chassis
- GE IC697MDL Series I/O Modules
These components form a stable distributed control network in legacy GE automation systems.
Popular GE Series 90-70 Modules
- IC697CPU780 – High-performance CPU module
- IC697ALG320 – Analog input module
- IC697MDL740 – Digital input module
- IC697PWR711 – Power supply module
- IC697BEM713 – Bus communication module
These modules are widely deployed in industrial automation systems requiring long-term operational stability.
