The GE IC697CPX782 is a high-performance single-slot CPU module for the GE Fanuc Series 90-70 PLC platform. It is designed for large-scale industrial automation, high-speed process control, and complex machine logic execution, delivering strong computing power with stable real-time performance.
Positioned as one of the more advanced CPUs in the 90-70 family, it is widely used in manufacturing plants, energy systems, water treatment facilities, and SCADA infrastructures, especially where high I/O density and fast scan cycles are required.
Technical Specifications
The IC697CPX782 combines high-speed processing with flexible communication and large memory capacity.
| Parameter | Specification |
|---|---|
| Model | IC697CPX782 |
| Product Type | PLC CPU Module |
| Series | GE Fanuc Series 90-70 |
| Processor | Intel 80486DX4 |
| Clock Speed | 96 MHz |
| Architecture | 32-bit floating-point CPU |
| Memory | 1 MB RAM + 256 KB NV-RAM |
| I/O Capacity | Up to 12,000 discrete I/O points |
| Analog Capacity | Up to 8,000 analog I/O points |
| Execution Speed | ~0.4 µs per Boolean instruction |
| Communication | 3 × serial ports (RS-232 / RS-485) |
| Ethernet Support | Via external communication modules |
| Programming | MS-DOS / Windows-based PLC tools |
| Operating Modes | RUN / STOP / RUN-disabled outputs |
| Slot Requirement | Single-slot rack module |
| Power Requirement | 5 VDC backplane (~3.1 A) |
This CPU is designed for high-speed deterministic control with strong expansion capability for large automation systems.
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | 44 mm × 292 mm × 222 mm |
| Weight | ≈ 0.5 kg |
Its compact single-slot form factor ensures compatibility with standard GE Series 90-70 racks such as CHS750, CHS790, and CHS791.
Recommended Related Models
IC697CPX782 is commonly paired with:
- GE IC697CHS790 PLC Rack
- GE IC697PWR711 Power Supply Module
- GE IC697BEM713 Bus Transmitter Module
- GE IC697BEM731 Genius Bus Controller
- GE IC697CMM741 / CMM742 Ethernet Modules
- GE IC697RCM711 Redundancy Communication Module
These components create a scalable and high-performance GE 90-70 automation architecture.
Popular GE Series 90-70 CPU Modules
- IC697CPU771 – Mid-range expandable CPU
- IC697CPU772 – High-speed floating-point CPU
- IC697CPU780 – Redundant hot standby CPU
- IC697CPU781 – High-capacity scalable CPU
- IC697CPX782 – Advanced high-speed CPU module
These CPUs are selected based on performance level, I/O scale, and system architecture requirements.
