Woodward 8200-1302 Compact With Display Controller
Woodward 8200-1302 Compact With Display Controller
0.0
Points
Brand:Woodward Item No.:8200-1302 Product Origin:USA Product Dimensions:220 × 127 × 80 mm Product Weight:1.8 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Woodward 8200-1302 Compact With Display Controller offers a combination of portability, reliability, and real-time monitoring for modern turbine and engine applications. Its compact design and integrated display simplify installation and operation, while the robust digital control architecture ensures precise, responsive, and safe control. By providing both local visualization and remote connectivity, this controller reduces system complexity and enhances operational confidence.
Technical Specifications
Specification
Details
Module Type
Compact Controller with Integrated Display
Control Capability
Turbine/engine speed, load, and alarm management
Communication
EtherNet/IP, Modbus TCP/RTU, Woodward Remote I/O
I/O Support
Up to 16 digital, 8 analog
Display
Multi-line LCD with status and alarm indicators
Environmental Ratings
Vibration, shock, industrial temperature tolerant
Operating Temperature
-20°C to 60°C (-4°F to 140°F)
Storage Temperature
-40°C to 85°C (-40°F to 185°F)
Mounting
Panel or skid mountable
Dimensions (H × W × D)
220 × 127 × 80 mm (8.7 × 5 × 3.1 in)
Weight
1.8 kg (3.97 lbs)
Applications
The Woodward 8200-1302 Compact With Display Controller is designed for compact and portable turbine or engine control applications, where real-time monitoring and user interface integration are required. Typical use cases include:
Small to medium steam or gas turbine control systems.
Backup or auxiliary power generation units.
Mobile or skid-mounted engine control systems.
Remote or distributed industrial installations requiring compact control.
Rapid deployment situations where a built-in display simplifies monitoring.
Its integrated display provides operators with real-time status updates, alarm information, and process feedback, reducing the need for external HMIs.
Advantages
Integrated Display: Provides immediate visual feedback on system status, alarms, and key parameters.
Compact Form Factor: Lightweight design allows installation in constrained spaces.
Versatile Connectivity: Supports both digital and analog I/O with standard communication protocols.
High Reliability: Designed to operate under industrial temperature, vibration, and electrical noise conditions.
Ease of Use: Intuitive interface reduces training requirements and accelerates deployment.
Technical FAQs
What type of display does the controller include?
A high-contrast, multi-line LCD providing system status, alarms, and process variables.
Can it control both turbines and engines?
Yes, the firmware allows configuration for either steam turbines or gas/diesel engines.
Which communication protocols are supported?
EtherNet/IP, Modbus TCP/RTU, and proprietary Woodward I/O networks.
Is it suitable for panel or skid installation?
Yes, compact size allows flexible mounting in panels or modular skids.
Can parameters be adjusted via the display?
Yes, the integrated interface allows parameter tuning, alarm acknowledgment, and diagnostics.
How does it handle electrical noise?
Built-in filtering and shielded connectors ensure signal integrity in harsh environments.
What is the maximum number of I/O points supported?
Up to 16 digital and 8 analog I/O points, configurable per application.
Is remote monitoring possible?
Yes, data can be transmitted to SCADA or central controllers via supported communication protocols.
What is the operating temperature range?
-20°C to 60°C (-4°F to 140°F), suitable for most industrial environments.
Does it support alarm logging and diagnostics?
Yes, the controller logs events, system faults, and alarm history accessible on the display or remotely.
