Allen Bradley 2711P-B4C20D PanelView Plus 400 Operator Terminal
Allen Bradley 2711P-B4C20D PanelView Plus 400 Operator Terminal
0.0
Points
Brand:Allen Bradley PLC Item No.:Allen Bradley 2711P-B4C20D Product Origin:USA Product Dimensions:152 × 185 × 90 mm Product Weight:0.8 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 2711P-B4C20D PanelView Plus 400 is a compact industrial Human Machine Interface (HMI) designed for machine control, operator interaction, and real-time process visualization in modern and legacy automation systems. As part of the PanelView Plus 6 family, this terminal delivers a balance of compact hardware design, Ethernet-based communication, and FactoryTalk View Machine Edition compatibility for streamlined industrial integration.
This model is widely used in OEM machinery, packaging systems, and small-to-midscale automation applications where space efficiency and stable performance are critical. Its combination of touchscreen input and keypad function keys provides operators with both fast interaction and precise control in demanding industrial environments.
Built on a Windows CE platform, the 2711P-B4C20D supports reliable Ethernet communication with Allen-Bradley Logix controllers, making it a versatile solution for distributed machine-level visualization.
Technical Specifications
Specification
Details
Manufacturer
Allen Bradley (Rockwell Automation)
Product Family
PanelView Plus 6 400
Catalog Number
2711P-B4C20D
Module Type
Operator Interface Terminal / HMI
Display Size
4-inch TFT Color LCD
Display Resolution
320 × 240 pixels
Input Method
Resistive touchscreen + keypad (function keys)
Function Keys
8 programmable keys
Communication Ports
Ethernet (EtherNet/IP), RS-232, USB
Operating System
Windows CE 6.0
Software Platform
FactoryTalk View Machine Edition
Input Voltage
24V DC (18–30V DC range)
Power Consumption
Approx. 20W
Memory
~64 MB Flash / RAM architecture
Enclosure Rating
NEMA 4X, IP66 (front panel)
Operating Temperature
0°C to 55°C
Storage Temperature
-20°C to 70°C
Dimensions
Approx. 152 × 185 × 90 mm
Weight
Approx. 0.6–0.8 kg
Recommended Related Models
Model
Description
2711P-B4C20D8
PanelView Plus 6 400 variant (enhanced memory/config)
2711P-T4C20D
Touch-only PanelView Plus 400 terminal
2711P-B5C20D
5.7-inch PanelView Plus 6 HMI
2711P-T7C4D8
PanelView Plus 700 modern HMI
2711P-T10C4D8
PanelView Plus 1000 HMI
1769-L24ER-QB1B
CompactLogix controller
1756-L81E
ControlLogix CPU module
Popular Allen Bradley Automation Products
Model
Product Category
1756-L81E
ControlLogix Controller
5069-IB16
Digital Input Module
1769-IF8
Analog Input Module
1734-AENTR
POINT I/O Ethernet Adapter
20G11NC072JA0NNNNN
PowerFlex 755 Drive
1606-XLE240E
Industrial Power Supply
1794-IE8
FLEX I/O Analog Module
2711R-T4T
PanelView 800 HMI
Industrial Applications
The Allen Bradley 2711P-B4C20D is commonly deployed in compact and mid-scale automation systems requiring reliable operator visualization and Ethernet-based PLC communication.
Typical applications include:
Packaging and labeling machines
Small production lines
Conveyor systems
Pump and compressor control panels
Food and beverage equipment
HVAC automation systems
Water treatment skids
OEM machine interfaces
Assembly automation cells
Retrofit control panel upgrades
Its compact footprint makes it especially suitable for equipment where cabinet space is limited but visualization requirements remain essential.
Key Advantages
Compact Industrial Design
The 4-inch HMI form factor allows integration into tight control panels without sacrificing core functionality.
Dual Input Flexibility
Touchscreen plus keypad inputs provide both intuitive navigation and precise operator control.
Industrial Ethernet Connectivity
Built-in EtherNet/IP support ensures stable integration with Rockwell Logix-based control systems.
Rugged Front Panel Protection
NEMA 4X and IP66-rated front protection supports operation in wet, dusty, and harsh industrial environments.
FactoryTalk Integration
Fully compatible with FactoryTalk View Machine Edition for standardized programming and lifecycle support.
Proven Installed-Base Reliability
Widely deployed across global OEM systems, offering stable long-term operational performance.
Technical FAQs
1. What is the Allen Bradley 2711P-B4C20D used for?
It is an industrial HMI used for machine control, process monitoring, and operator interface applications.
2. What display does it use?
It features a 4-inch color TFT LCD with 320 × 240 resolution.
3. Does it support touchscreen input?
Yes, it uses a resistive touchscreen along with keypad function keys.
4. What operating system does it run?
It runs Windows CE 6.0.
5. What software is used for programming?
It is configured using FactoryTalk View Machine Edition.
6. What communication interfaces are available?
It supports Ethernet (EtherNet/IP), RS-232, and USB ports.
7. What is the power requirement?
It operates on 24V DC input power (18–30V DC range).
8. Is the 2711P-B4C20D still manufactured?
No. It is a discontinued PanelView Plus 6 model but remains widely used in installed systems.
9. What industries commonly use it?
It is used in manufacturing, packaging, automotive, food processing, and process automation industries.
10. Why is it still widely used today?
Because of its strong reliability, compact design, EtherNet/IP compatibility, and long-term support for existing Allen-Bradley automation systems.
