GE IC200CHS122 Fuse-Style Interposing I/O Expansion Base Module
GE IC200CHS122 Fuse-Style Interposing I/O Expansion Base Module
0.0
Points
Brand:GE Fanuc PLC Item No.:GE IC200CHS122 Product Origin:USA Product Dimensions:137 × 126 × 75 mm Product Weight:1.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200CHS122 is a fuse-style interposing I/O expansion base module designed for the VersaMax distributed control system. It works in conjunction with the IC200CHS121 main base to extend I/O connectivity to the “B-side” terminals of VersaMax modules. Engineered for industrial environments that demand both circuit protection and scalable wiring architecture, this module integrates individual fusing for each channel while maintaining clean and structured field wiring. It is widely valued in systems where uptime, safety, and easy maintenance are critical performance priorities.
The IC200CHS122 is specifically required when VersaMax I/O modules include “B-side” terminals, ensuring complete system connectivity and protected signal distribution.
Recommended Related Models
IC200CHS121 Fuse-Style Main Base Module
IC200CHS003 Connector I/O Carrier
IC200CBL105 Expansion Connection Cable
IC200MDL750 Digital Output Module
IC200MDL650 Digital Input Module
Popular GE VersaMax System Modules
IC200CPU001 Controller Module
IC200PWR001 Power Supply Module
IC200ERM002 Expansion Receiver Module
IC200ALG240 Analog Input Module
IC200MDL940 Relay Output Module
Application Scenarios
The IC200CHS122 is widely used in industrial automation systems where safe signal expansion and per-channel protection are required. It is commonly applied in manufacturing automation, energy distribution systems, process plants, and heavy machinery control panels. When paired with the main base, it enables full I/O coverage while ensuring that faults on one channel do not compromise the entire system. Its fused architecture is particularly valuable in environments with sensitive field devices or long wiring runs.
Key Advantages
This module delivers strong engineering value through its integrated fuse protection, scalable architecture, and simplified wiring design. Each channel is individually protected, reducing the risk of cascading failures. The structured terminal layout improves cabinet organization and speeds up troubleshooting. Its modular expansion design allows engineers to scale I/O capacity without redesigning the control system. Combined with robust industrial construction, it ensures stable performance even in electrically noisy environments, making it a dependable choice for mission-critical automation systems.
Technical FAQs
What is the main purpose of IC200CHS122?
It expands VersaMax I/O systems by providing fused “B-side” field wiring connections.
Is IC200CHS122 usable alone?
No, it must be paired with IC200CHS121 main base.
How many I/O points does it support?
It supports 16 expansion I/O channels.
What type of protection does it provide?
Each channel includes a dedicated 0.5A fuse for protection.
What connector is used for expansion?
It uses a J2 connector linking to the main base.
Does it include wiring cables?
Yes, the expansion cable is typically included with the module.
What is the benefit of auxiliary terminals?
They simplify two-wire device connections without extra terminal blocks.
Can it handle high-voltage systems?
Yes, it supports up to 264 VAC with transient tolerance up to 300 VAC.
What industries commonly use this module?
Manufacturing, utilities, process control, and energy systems.
What is its biggest operational advantage?
Safe expansion of I/O capacity with built-in per-channel fault protection.
