The Allen Bradley 2711P-T6M5A8 PanelView Plus 6 is a compact industrial Human-Machine Interface (HMI) designed for operator-level visualization and machine control in factory automation systems. It provides a reliable communication bridge between PLC systems and operators, enabling real-time monitoring, alarm handling, and process interaction.
Although part of an older generation PanelView Plus 6 lineup, it remains widely used in legacy automation systems due to its stability, simple architecture, and proven industrial durability.
Technical Specifications
| Category | Specification |
|---|---|
| Product Family | PanelView Plus 6 |
| Model Number | 2711P-T6M5A8 |
| Display Type | Monochrome TFT LCD |
| Screen Size | 5.7 inches |
| Resolution | 320 × 240 pixels |
| Input Type | Resistive touchscreen |
| Operating System | Windows CE |
| Communication Port | RS-232 |
| Input Voltage | 100–240V AC |
| Memory | 256 MB RAM |
| Backlight | Non-replaceable |
| Application Software | FactoryTalk View Machine Edition |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | 152 mm × 185 mm × 68 mm |
| Weight | Approx. 1.81 kg |
Recommended Related Models
To maintain or upgrade PanelView Plus 6 systems, the following related models are commonly used:
- Allen Bradley 2711P-T6C5A8 PanelView Plus 6 (color version)
- Allen Bradley 2711P-T10C4D8 PanelView Plus 7 (modern replacement)
- Allen Bradley 1769-L33ER CompactLogix Controller
- Allen Bradley 1756-L8 ControlLogix CPU Modules
- Allen Bradley 2711P-RN6 Communication Module (legacy systems)
These options support system maintenance, migration, or upgrade planning.
