Siemens 6AG4010-6AD31-0FX5 SIMATIC IPC3000 SMART V3 Industrial PC

Where It Excels in Industrial Use

• Centralized automation control: The 19-inch, 4U rack architecture provides a solid computing platform for SCADA, HMI, machine supervision, and plant-level automation systems.

• Industrial data processing: Dual Gigabit Ethernet interfaces allow the IPC to participate in high-speed plant networks while supporting remote-start and LAN wake functionality.

• Machine and production-line integration: A broad selection of USB, serial, display, keyboard, and mouse interfaces makes the platform practical for connecting both modern and legacy industrial equipment.

• Expansion-heavy control systems: The combination of three PCI slots and several PCI Express slots provides considerable room for communication, acquisition, motion-control, and other specialized interface cards.

• Control-cabinet computing: Its rack-mounted 4U construction makes it particularly suitable for centralized control cabinets where serviceability, expansion, and conventional rack installation are important.

Key Strengths at a Glance

• Professional 19-inch rack format: The 4U chassis fits conventional industrial rack environments and provides more internal expansion room than compact embedded industrial PCs.

• Dual Gigabit networking: Two RJ45 Ethernet ports support 10/100/1000 Mbps operation and provide LAN Wake and remote-start functions.

• Extensive I/O connectivity: The platform combines front USB 2.0, rear USB 3.0, serial COM, VGA, DisplayPort, PS/2, and audio interfaces for flexible system integration.

• Mixed PCI and PCIe expansion: Three PCI slots are supplemented by PCIe x4 and PCIe x16 interfaces, allowing the system to accommodate a broad range of industrial expansion hardware.

• Flexible drive architecture: One 3.5-inch drive position and three 5.25-inch positions provide useful options for industrial storage and removable-media configurations.

• Wide AC input range: The documented IPC3000 SMART V3 platform supports 100–240 VAC input, with 350 W and 500 W power-supply variants documented for the 6AG4010-6-series family.

Technical FAQs

1. What type of industrial computer is the Siemens 6AG4010-6AD31-0FX5?

The 6AG4010-6AD31-0FX5 is part of the SIMATIC IPC3000 SMART V3 industrial rack-PC family, designed for industrial automation, visualization, monitoring, and data-processing applications.

2. How is the IPC3000 SMART V3 installed?

The system uses a 19-inch, 4U rack-oriented chassis, making it suitable for industrial cabinets, equipment racks, and centralized automation installations.

3. How many Ethernet interfaces does the IPC3000 SMART V3 provide?

The platform provides two RJ45 Ethernet interfaces supporting 10/100/1000 Mbps communication, with LAN Wake and remote-start functionality.

4. What USB interfaces are available?

The documented configuration provides two USB 2.0 ports on the front panel and four USB 3.0 ports on the rear panel, with additional internal USB connections available on the motherboard.

5. Which serial communication standards are supported?

Two rear-panel COM interfaces support RS232, RS485, and RS422 modes, while additional motherboard COM interfaces support RS232 communication.

6. Which display interfaces are available?

The IPC3000 SMART V3 platform provides one VGA interface for analog display connection and one DisplayPort interface for digital display connection.

7. What expansion architecture does the IPC3000 SMART V3 use?

The platform includes three conventional PCI slots, two PCIe x4 slots operating with one PCIe 2.0 lane, one PCIe x4 slot supporting two or four PCIe 2.0 lanes, and one PCIe x16 slot using PCIe 3.0.

8. What type of audio controller is integrated?

The IPC3000 SMART V3 uses a Realtek ALC887 high-definition audio codec with 5.1-channel capability, together with microphone, audio-input, and audio-output connections.

9. What power input does this industrial PC support?

The 6AG4010-6-series documentation specifies 100–240 VAC operation at 50–60 Hz, with both 350 W and 500 W power-supply configurations available within the family.

10. Can the exact processor and storage configuration be identified from the order number alone?

The IPC3000 SMART V3 family contains multiple hardware configurations, and Siemens states that the processor configuration is determined by the individual order number. Because a public Siemens document specifically mapping 6AG4010-6AD31-0FX5 to its CPU, RAM, and storage configuration was not located, those details should be verified against the original order documentation rather than inferred from another IPC3000 model.
