The Bently Nevada 3500/22-02-00 Transient Data Interface Module is a high-performance interface unit designed to capture and transmit high-speed transient data from 3500 monitoring systems. It ensures that key events in turbines, compressors, and generators are accurately recorded and available for analysis. Rack-compatible, robust, and reliable, this module is essential for predictive maintenance, system diagnostics, and real-time monitoring in industrial environments.

Technical Specifications

Parameter	Specification
Dimensions	241.3 mm × 24.4 mm × 241.8 mm
Weight	0.91 kg
Function Type	Transient Data Interface Module
Channels	Supports multi-module data acquisition
Operating Temperature	-20°C to +60°C
Mounting Type	Rack-mounted 3500/22 series module
Material	Industrial-grade electronic housing
