Introduction

The 2711P-T9W22D9P PanelView Plus 7 represents Rockwell Automation’s performance-focused evolution of its HMI platform, offering improved computing capability, enhanced connectivity, and modernized visualization performance.

It is engineered to bridge operator interaction with high-speed industrial Ethernet control systems, providing a stable and scalable interface for modern automation architectures. Its widescreen design and upgraded processing capabilities make it suitable for complex applications requiring richer graphics and faster response times.

Technical Specifications

Parameter	Specification
Model	2711P-T9W22D9P
Series	PanelView Plus 7 Performance
Display	9-inch WVGA widescreen TFT
Communication	EtherNet/IP, USB, RS-232
Network Features	DLR support
Input Voltage	24 V DC
Operating System	Windows 10 IoT (industrial embedded)
Memory	512 MB RAM / 512 MB nonvolatile memory
Operating Temperature	0°C to 55°C
Mounting Type	Panel mount
Dimensions	280 × 69.6 × 190 mm
Weight	1.58 kg (3.48 lb)

Applications

The Allen-Bradley 2711P-T9W22D9P PanelView Plus 7 Operator Interface is designed for modern industrial visualization systems where high-performance HMI interaction and seamless PLC integration are required.

Typical applications include:

Advanced machine-level operator control in automated production lines
Real-time monitoring of ControlLogix and CompactLogix systems
SCADA visualization terminals in distributed industrial networks
Packaging, food & beverage, and material handling systems
High-speed production diagnostics and alarm management
OEM machinery requiring high-resolution operator interfaces
Industrial Ethernet-based control architectures with DLR redundancy

This model is especially suited for new-generation automation systems requiring higher processing performance and improved visualization compared to PanelView Plus 6 platforms.

Advantages

Next-generation PanelView Plus 7 Performance architecture
9-inch widescreen WVGA display for improved operator visibility
Native EtherNet/IP and DLR support for resilient industrial networking
Enhanced processing performance for complex HMI applications
Windows-based industrial operating system for flexible runtime capability
High integration compatibility with Rockwell Logix controllers
Remote monitoring support via VNC and web-based tools
Expanded memory capacity for larger visualization projects
Rugged industrial-grade design for continuous operation environments
Designed for long lifecycle deployment in modern automation systems

Technical FAQs (10 Technical Questions)

1. Does the 2711P-T9W22D9P support EtherNet/IP communication?
Yes, it supports native EtherNet/IP for seamless PLC integration.

2. Can it be used with ControlLogix PLC systems?
Yes, it is fully compatible with ControlLogix and CompactLogix controllers.

3. Does this model support Device-Level Ring (DLR)?
Yes, it supports DLR for network redundancy and fast recovery.

4. What operating system does it use?
It runs a Windows 10 IoT-based industrial operating system.

5. Can applications be updated remotely?
Yes, remote diagnostics and updates are supported depending on network configuration.

6. Does it support FactoryTalk View ME applications?
Yes, it is designed for FactoryTalk View Machine Edition runtime environments.

7. Is VNC remote access supported?
Yes, VNC-based remote monitoring is supported for operator visibility.

8. Can it handle complex HMI graphics and alarms?
Yes, it is optimized for high-performance visualization and alarm handling.

9. Is it suitable for harsh industrial environments?
Yes, it is built for industrial vibration, temperature variation, and electrical noise resistance.

10. Can it replace PanelView Plus 6 systems directly?
Yes, it is commonly used as an upgrade path from PanelView Plus 6 platforms.
