The GE DS200TCPSG1AME is a DC Input Power Supply Board designed for the GE Mark V Speedtronic turbine control system. It plays a foundational role in system power architecture by converting and distributing 125 VDC input power into multiple regulated voltage levels required by turbine control, protection, and monitoring subsystems.
This module is considered one of the core electrical lifelines of the Mark V platform, ensuring stable operation of processors, I/O modules, servo systems, and analog instrumentation circuits in demanding industrial environments.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200TCPSG1AME |
| Series | Mark V Speedtronic |
| Product Type | DC Input Power Supply Board |
| Functional Abbreviation | TCPS |
| Function | Power conversion & system voltage distribution |
| Input Voltage | 125 VDC (from PD core) |
| Output Functions | RTD supply, servo valve current, processor power |
| System Role | Central power distribution (R core module) |
| Connectors | J1, 2PL, JC, JP1, JP2 |
| Protection | Fuses, MOVs, heat sinks, transformers |
| Configuration | No software/hardware programming required |
| PCB Features | Factory-drilled, coated industrial protection layer |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 160 × 160 × 120 mm |
| Weight | approx. 0.8 kg |
| Mounting Type | Rack-mounted PCB module |
This architecture is designed for high electrical stability, ensuring uninterrupted power delivery across the turbine control ecosystem.
