Allen Bradley 2711-T10C8L1 PanelView 1000 Operator Interface
Allen Bradley 2711-T10C8L1 PanelView 1000 Operator Interface
0.0
Points
Brand:Allen Bradley PLC Item No.:2711-T10C8L1 Product Origin:USA Product Dimensions:370 x 112 x 282 mm Product Weight:3.6 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The 2711-T10C8L1 is part of the Allen-Bradley PanelView 1000 series, a widely deployed legacy HMI platform used for operator interaction in industrial control systems.
It provides stable visualization and control functions for PLC-driven machinery, especially in environments where long-term system consistency is prioritized over modernization. Despite being discontinued, it remains widely installed across global industrial facilities due to its durability and compatibility with older Allen-Bradley automation networks.
Technical Specifications
Parameter
Specification
Model
2711-T10C8L1
Series
PanelView 1000
Display Size
10.1-inch color TFT
Resolution
640 × 480 pixels
Touch Type
Resistive touchscreen
Communication
DH+ (Data Highway Plus), RS-232 printer port
Input Voltage
18–32 V DC (typical industrial configuration)
Power Consumption
~24 W
Memory
~256 KB application memory
Software
PanelBuilder32
Mounting Type
Panel mount
Operating Temperature
0°C to 55°C
Dimensions
370 × 112 × 282 mm
Weight
3.6 kg (7.94 lb)
Applications
The Allen-Bradley 2711-T10C8L1 PanelView 1000 Operator Interface is designed for legacy industrial automation systems requiring reliable operator visualization and direct PLC communication in established production environments.
It is commonly used in:
SLC 500 and early ControlLogix machine control systems
Industrial process monitoring and operator station panels
Packaging, material handling, and discrete manufacturing lines
SCADA front-end visualization terminals in legacy infrastructure
Long-life installed base automation systems in heavy industry
This terminal remains highly relevant in maintenance-driven industries where system continuity and spare-part compatibility are more important than modernization.
Advantages
Large 10-inch industrial touchscreen for clear operator visibility
Proven PanelView 1000 architecture with long-term field reliability
Built-in DH+ communication for legacy Allen-Bradley networks
RS-232 printer port support for industrial reporting systems
Rugged enclosure designed for harsh factory environments
Stable performance in 24/7 continuous production operations
Compatible with PanelBuilder32 engineering workflow
Strong installed base ensures long-term maintenance availability
Reliable operation in electrically noisy industrial environments
Ideal for retrofit and legacy system extension projects
Technical FAQs (10 Technical Questions)
1. What communication protocol does the 2711-T10C8L1 use?
It primarily supports Data Highway Plus (DH+) and RS-232 printer communication.
2. Can it connect to modern Ethernet-based PLCs?
No, it does not natively support Ethernet communication.
3. What software is used for configuration?
It is programmed using PanelBuilder32 software.
4. Is this model still in production?
No, it is a legacy discontinued PanelView 1000 terminal.
5. Does it support ControlLogix systems?
Only indirectly through legacy communication networks or gateway devices.
6. Can the backlight be replaced?
Yes, the backlight is field-replaceable depending on revision.
7. Does it support USB or SD card storage?
No native USB or SD expansion is supported.
8. Is it suitable for harsh environments?
Yes, it is designed for industrial vibration, EMI, and temperature variations.
9. What type of touchscreen does it use?
It uses an industrial resistive touchscreen with fixed touch grid cells.
10. What is the main limitation of this model today?
Limited communication flexibility and outdated software ecosystem compared to modern PanelView Plus and PanelView 800 series.
