Emerson KJ4010X1-BF1 Left-side Local Bus Extension Cable
Emerson KJ4010X1-BF1 Left-side Local Bus Extension Cable
0.0
Points
Brand:Emerson Module Item No.:KJ4010X1-BF1 Product Origin:USA Product Dimensions:128 × 30 × 85 mm Product Weight:0.231 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Emerson KJ4010X1-BF1 Left-side Local Bus Extension Cable is a critical component in DeltaV distributed control systems, designed to extend LocalBus communication between I/O carriers. It enables stable and reliable data transfer across modular system sections, supporting flexible and scalable automation architectures.
Technical Specifications
Parameter
Specification
Product Name
Emerson KJ4010X1-BF1
Product Type
Left-side Local Bus Extension Cable
System
Emerson DeltaV DCS
Function
LocalBus communication extension
Dimensions
128 × 30 × 85 mm
Weight
0.231 kg
Communication
DeltaV LocalBus
Installation
Requires system power OFF
Application
Industrial distributed control systems
Recommended Related Models
Model Number
Product Name
KJ4010X1-BG1
Right-side LocalBus Extension Cable
KJ4001X1-GA1
LocalBus Right-side Extension Cable
KJ4003X1-BC1
VerticalPLUS Power/Controller Carrier
KJ4003X1-BF1
VerticalPLUS End Extender
Popular Related Models
Model Number
Product Name
KJ3008X1-BA1
Event Sequence Module
KJ3201X1-BA1
DeltaV Digital Input Module
KJ3203X1-BA1
DeltaV Digital Output Module
KJ3002X1-BA1
DeltaV Analog Input Module
Applications
• Emerson DeltaV distributed control systems requiring reliable LocalBus communication between I/O carriers.
• Industrial automation systems where multiple DeltaV racks need stable high-speed data exchange.
• Power generation plants using DeltaV DCS for coordinated turbine, boiler, and balance-of-plant control.
• Oil and gas and petrochemical facilities where uninterrupted bus communication is critical for process safety.
• Large-scale process control architectures requiring modular expansion of LocalBus networks across cabinets.
Key Advantages
• Ensures stable and high-speed LocalBus signal transmission between DeltaV system components.
• Designed for industrial-grade environments with strong resistance to vibration, heat, and electrical noise.
• Enables flexible system expansion by supporting left-side LocalBus extension in modular architectures.
• Maintains communication integrity across I/O carriers for reliable distributed control performance.
• Rugged construction supports long-term operation in continuous-duty industrial systems.
Technical FAQs
1. What is the main function of the KJ4010X1-BF1 cable?
It extends the LocalBus connection on the left side of Emerson DeltaV I/O carrier systems.
2. What system is it used with?
It is designed for Emerson DeltaV distributed control systems (DCS).
3. What is LocalBus in DeltaV architecture?
It is the internal high-speed communication bus linking controllers and I/O modules.
4. Can it be used for long-distance wiring?
No. LocalBus extensions are short-range and must follow system installation limits.
5. Is it suitable for harsh environments?
Yes. It is built for industrial conditions with vibration, heat, and electrical interference.
6. Does it require power?
No. It functions as a communication extension cable only.
7. Can it be installed while the system is running?
No. Installation requires system power to be off for safety.
8. Where is it commonly used?
It is used in power plants, refineries, chemical plants, and large process industries.
9. What happens if installed incorrectly?
Improper installation may cause LocalBus communication failure or system faults.
10. Why is LocalBus extension important?
It allows scalable DeltaV system design by connecting multiple I/O carriers across cabinets.
