Allen Bradley 5069-AEN2TR Compact 5000 I/O EtherNet/IP Adapter
Allen Bradley 5069-AEN2TR Compact 5000 I/O EtherNet/IP Adapter
0.0
Points
Brand:Allen Bradley PLC Item No.:5069-AEN2TR Product Origin:USA Product Dimensions:136.8 x 98.1 x 123 mm Product Weight:0.68 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen-Bradley 5069-AEN2TR Compact 5000 EtherNet/IP Adapter is a next-generation industrial communication module designed to connect distributed I/O systems with high-speed control networks. It enables seamless data exchange between controllers and remote I/O racks, improving system scalability and reducing wiring complexity.
Engineered for modern smart factories, this adapter supports advanced network topologies and ensures reliable real-time communication for critical automation processes.
Technical Specifications
Parameter
Specification
Model
5069-AEN2TR
Product Type
Compact 5000 EtherNet/IP I/O Adapter
Network Protocol
EtherNet/IP
Ports
2 × RJ45 Ethernet ports
Topology Support
Linear / Device Level Ring (DLR)
I/O Platform
Compact 5000 Series
Communication Speed
10/100/1000 Mbps (auto-negotiation)
Mounting Type
DIN rail / chassis integration
Operating Temperature
-25 to 60 °C
Dimensions
136.8 × 98.1 × 123 mm
Weight
0.68 kg (1.50 lb)
Diagnostics
Network status, module health indicators
Applications
The 5069-AEN2TR is widely used in modern industrial automation systems where high-speed Ethernet communication and distributed I/O expansion are required:
Distributed I/O systems in manufacturing automation lines
High-speed packaging and sorting equipment
Machine control architectures using CompactLogix controllers
Process automation systems requiring real-time EtherNet/IP communication
Robotics and motion control systems with modular I/O expansion
Its dual-port design supports linear and ring topologies, improving network resilience and installation flexibility.
Advantages
Dual-port EtherNet/IP design supports linear and Device Level Ring (DLR) topologies
High-speed deterministic communication for real-time industrial control
Seamless integration with Compact 5000 I/O platform
Simplified system expansion without major control architecture changes
Enhanced network diagnostics for fast fault detection
Reduced wiring complexity through distributed architecture
Industrial-grade robustness for harsh factory environments
Technical FAQs
1. What system is this adapter compatible with?
It is designed for the Compact 5000 I/O platform within Allen-Bradley control systems.
2. Does it support redundant network topology?
Yes, it supports Device Level Ring (DLR) redundancy for improved network reliability.
3. Can it be used in real-time control applications?
Yes, it is optimized for deterministic EtherNet/IP communication.
4. Does it require a separate power supply?
Yes, it operates as part of the I/O system and requires appropriate system power configuration.
5. How many network ports does it include?
It features two EtherNet/IP ports for flexible network topology design.
6. Is it suitable for high-speed production lines?
Yes, it is designed for high-speed industrial automation environments.
7. Can it be integrated with CompactLogix controllers?
Yes, it is fully compatible with CompactLogix control architectures.
8. Does it support remote diagnostics?
Yes, it provides network and module-level diagnostic capabilities.
9. Can it be used in modular I/O expansions?
Yes, it is specifically designed for scalable distributed I/O systems.
10. Is configuration required before operation?
Yes, network addressing and system configuration are required during setup.
