Brand:Bently Nevada PLC Item No.:27465-01 Product Origin:USA Product Dimensions:250 x 35 x 102 mm Product Weight:0.8 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Bently Nevada 27465-01 valve position sensor is part of an industrial measurement system used to provide accurate feedback on valve movement and position. It plays a critical role in ensuring that control valves operate correctly within their intended stroke range, improving both process efficiency and equipment safety.
Technical Specifications
Parameter
Specification
Model
27465-01
Sensor Type
Valve position transducer
Measurement Principle
Linear displacement (LVDT-based system typical)
Measurement Range
~254 mm (10 in) typical system configuration
Output Signal
Analog voltage proportional to position
Housing Dimensions
250 × 35 × 102 mm
Linearity
High-precision industrial grade (≤ ±1% typical)
Operating Temperature
-18°C to +71°C
Protection
Industrial sealed housing
Mounting
Fixed mechanical installation on valve actuator
Weight
0.8 kg
Application
Valve stroke and position monitoring
Recommended Related Models
Model
Product Name
24765-01-01
Bently Nevada Case Expansion Transducer System
330780-51-00
Bently Nevada Proximity Probe System
330850-90-00
Bently Nevada Proximitor Sensor Module
330103-00-12-10-02-00
Bently Nevada Proximity Probe System
Popular Related Models
Model
Product Name
330881-28-04-145-03-02
Bently Nevada PROXPAC XL System
330780-90-00
Bently Nevada Standard Proximity Probe
330500-02-00
Bently Nevada Vibration Probe
330980-50-00
Bently Nevada XL NSv Proximity Sensor
Applications
• Steam turbine control valve position monitoring in power generation systems.
• Industrial process control valves in oil & gas and petrochemical plants.
• Flow regulation systems requiring continuous valve stroke feedback.
• Compressor anti-surge and bypass valve position monitoring systems.
• Heavy industrial automation systems integrated with DCS and PLC control loops.
• Critical safety and shutdown systems requiring reliable valve position verification.
Key Advantages
• Provides continuous linear position feedback for precise valve control monitoring.
• Rugged industrial design ensures stable operation in high vibration and harsh environments.
• High measurement accuracy improves process control stability and system responsiveness.
• Non-contact sensing principle reduces mechanical wear and extends service life.
• Compatible with turbine supervisory and industrial control architectures.
• Designed for long-term operation in mission-critical industrial applications.
Technical FAQs
Q1: What is the main function of the 27465-01 sensor?
It measures the linear position of control valves for monitoring and feedback.
Q2: Is it a contact or non-contact sensor?
It typically uses a non-contact displacement measurement principle.
Q3: What type of systems is it used in?
It is used in turbine control systems, process valves, and industrial automation systems.
Q4: What signal does it output?
It provides an analog position signal proportional to valve stroke.
Q5: Can it be used for partial valve opening measurement?
Yes, it provides continuous position feedback across the full stroke range.
Q6: Is it suitable for harsh industrial environments?
Yes, it is designed for industrial temperature, vibration, and contamination conditions.
Q7: Does it require external power?
Yes, it typically operates with a dedicated transducer or monitoring module.
Q8: Is it used in safety systems?
Yes, it is often integrated into shutdown and interlock logic systems.
Q9: Does it require frequent calibration?
No, it is designed for long-term stable operation with minimal recalibration.
Q10: What industries commonly use it?
Power generation, oil & gas, petrochemical, and heavy process industries.
