Brand:Schneider PLC Item No.:Schneider ATV340D55N4E Product Origin: France Product Dimensions:908 × 271 × 309 mm Product Weight:58 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV340D55N4E is a variable speed drive from the Altivar Machine ATV340 series, designed for controlling the speed and torque of three-phase asynchronous and synchronous motors.
It is typically used in industrial automation systems where motor speed regulation is required for process control, machinery operation, and system coordination. The drive supports integration with automation networks and can be configured for different application profiles depending on system requirements.
The ATV340 series is intended for machine builders and industrial equipment manufacturers requiring flexible motor control in compact drive architectures.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model
ATV340D55N4E
Product Type
Variable Speed Drive
Series
Altivar Machine ATV340
Supply Voltage
380–480 VAC, 3-phase
Motor Power
55 kW (heavy duty)
Output Current
145 A (typical configuration)
Motor Types
Asynchronous and synchronous motors
Control Modes
Open loop / closed loop control
Communication Interfaces
Ethernet, Modbus
Safety Functions
Integrated safety functions (depending on configuration)
Mounting Type
Panel / chassis mounting
Cooling Method
Forced air cooling
Protection Level
IP20
Operating Temperature
Industrial cabinet environment (derating may apply)
Dimensions & Weight
Item
Specification
Dimensions (H × W × D)
908 × 271 × 309 mm
Weight
Approx. 58 kg
Compatible / Related Models
Schneider ATV340D11N4E
Schneider ATV340D22N4E
Schneider ATV340D37N4E
Schneider ATV340D45N4E
Schneider ATV340D75N4E
ATV340 Series Overview
ATV340D11N4E
ATV340D15N4E
ATV340D22N4E
ATV340D30N4E
ATV340D37N4E
ATV340D45N4E
ATV340D55N4E
ATV340D75N4E
Typical Applications
The ATV340D55N4E is used in a wide range of industrial machine applications, including:
Conveyor systems
Packaging machinery
Material handling systems
Pumps and pumping stations
Ventilation and air handling systems
Industrial compressors
Processing machines
Hoisting and lifting equipment
Manufacturing automation systems
General industrial machinery control
Product Characteristics
Designed for variable speed motor control in industrial systems
Supports multiple motor control methods depending on configuration
Suitable for integration into machine-level automation systems
Compatible with Ethernet-based industrial networks
Built for installation inside electrical control cabinets
Supports configuration through engineering software tools
Intended for continuous industrial operation
Suitable for both standard and heavy-duty load profiles
Works with a wide range of industrial motors
Designed for system integration in automated production environments
Technical FAQs
1. What is the ATV340D55N4E used for?
It is used to control the speed and torque of three-phase industrial motors.
2. What type of product is it?
It is a variable speed drive (VSD / VFD).
3. What voltage does it support?
It operates on a three-phase 380–480 VAC supply.
4. What motor power can it control?
It is typically used with motors up to 55 kW in heavy-duty applications.
5. Which motor types are supported?
It supports both asynchronous and synchronous motors.
6. Does it support communication networks?
Yes, it supports Ethernet and Modbus communication depending on configuration.
7. Where is it installed?
It is installed inside industrial control cabinets or machine enclosures.
8. What industries use it?
It is used in manufacturing, material handling, HVAC systems, pumping systems, and industrial machinery.
9. Does it include built-in safety functions?
It supports integrated safety functions depending on system configuration.
10. What is its main role in a system?
Its main role is to regulate motor speed and torque according to process requirements.
