Brand:Schneider PLC Item No.:ATS22C25Q Product Origin:France Product Dimensions:425 x 206 x 299 mm Product Weight:33 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ATS22C25Q belongs to Schneider Electric’s Altistart 22 series, engineered for high-performance soft starting of three-phase induction motors in industrial environments. It uses controlled voltage ramp technology to reduce inrush current and minimize mechanical stress during motor startup and shutdown.
Designed for high-power applications, it combines SCR-based control with integrated bypass functionality, delivering efficient thermal management and stable long-term operation. Its rugged industrial design ensures reliable performance in demanding environments such as heavy manufacturing, infrastructure, and process industries.
ATS22C14Q – Widely used in HVAC and pumping applications
ATS22C11Q – Common in general industrial automation systems
ATS480C25Q – Modern upgraded alternative in high-performance systems
Applications
The Schneider ATS22C25Q Soft Starter Module is designed for heavy-duty industrial motor control applications where high power handling, controlled torque, and reduced electrical stress are essential. It is widely used in large-scale automation systems requiring reliable motor starting under demanding load conditions.
Typical applications include:
Large industrial pumping stations (water supply, wastewater, process pipelines)
High-capacity HVAC systems and chillers
Industrial compressors and air handling plants
Conveyor systems for bulk material transport
Mining, cement, steel, and heavy processing equipment
High-power three-phase induction motor drives
Its controlled voltage ramping helps reduce mechanical shock and electrical surges, significantly improving system reliability and extending equipment lifespan in high-load environments.
Advantages
High-current industrial design for heavy motor loads up to 132 kW class
Smooth torque control reduces mechanical stress on drivetrain components
Integrated bypass function improves thermal efficiency after startup
Stable soft start/stop improves process continuity and equipment protection
Robust construction for harsh industrial environments
Compatible with PLC and industrial automation systems
Built-in motor protection enhances system safety and reliability
Reduces downtime and maintenance costs in continuous operation
Technical FAQs (10 Questions)
Q1: What motor type is compatible with ATS22C25Q?
It is designed for three-phase asynchronous induction motors.
Q2: What is the rated current of this model?
The ATS22C25Q is rated at 250 A.
Q3: What is the typical motor power range?
It supports up to 132 kW at 400–440 V line connection, depending on configuration.
Q4: What supply voltage does it support?
It operates in the 230–440 V AC range.
Q5: Does it include an internal bypass function?
Yes, it features an integrated bypass contactor for reduced heat dissipation.
Q6: Can it be used in pump systems?
Yes, it is widely used in pumping applications to reduce water hammer effects.
Q7: Is it suitable for HVAC systems?
Yes, it is commonly used in ventilation and chiller systems.
Q8: Does it support PLC integration?
Yes, it integrates with standard industrial automation systems.
Q9: Does it require complex commissioning?
No, it supports straightforward parameter setup and commissioning.
Q10: Can it be used for retrofit upgrades?
Yes, it is commonly used for modernization of existing motor control systems.
