Yokogawa ASD533 8‑Channel Digital Output Module for CENTUM and Industrial Automation Systems
Yokogawa ASD533 8‑Channel Digital Output Module for CENTUM and Industrial Automation Systems
0.0
Points
Brand:Yokogawa Electric Item No.:Yokogawa ASD533 Product Origin:Japan Product Dimensions:100 × 70 × 35 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Yokogawa ASD533 is a reliable digital output module designed for use with Yokogawa distributed control systems (DCS) such as CENTUM VP and CENTUM CS 3000. This module provides isolated digital outputs that interface with field devices—such as relays, solenoids, indicators, and actuators—allowing automation systems to execute discrete control logic with precision and safety.
Built with industrial‑grade components and robust isolation barriers, the ASD533 is suited for applications where signal integrity, system safety, and reliable switching performance are essential. Its compact, rack‑mount design facilitates integration into control cabinets and I/O frames in critical automation environments.
Technical Specifications
Parameter
Specification
Model
ASD533
Manufacturer
Yokogawa Electric Corporation
Product Type
Digital Output Module
Compatible Systems
Yokogawa DCS (CENTUM VP / CS 3000)
Output Channels
8 isolated digital outputs
Output Voltage
Up to 24 V DC
Output Current
Up to 1 A per channel
Output Signal
>12 V at I = 40 mA typ.
Isolation Barrier
Yes (1500 V AC)
Operating Temperature
-20 °C to +70 °C
Response Time
~10 ms
Mounting
Rack / panel integration
Dimensions (L × W × H)
100 × 70 × 35 mm
Weight
0.30 kg
This module’s 8 isolated output channels and integrated barrier design enhance safety and protect both control systems and field devices from electrical interference or unexpected faults.
Recommended Related Modules
Model
Description
Yokogawa ASD143
16‑channel digital input module
Yokogawa ASI533
8‑channel current/analog output module
Yokogawa ADV551
High‑density digital output module
Yokogawa ADV161
64‑channel digital input module
Yokogawa ADV561
64‑channel digital output module
Popular Yokogawa Automation Hardware
Model
Module Type
EJX630A
Gauge Pressure Transmitter
EJX530A
Gauge/Absolute Pressure Transmitter
F3CU04
Temperature Control / PID Module
SE8000
Process Controller
S‑series I/O
Modular input/output platform
Typical Industrial Applications
The Yokogawa ASD533 Digital Output Module is widely used in automation environments demanding robust discrete control outputs:
Distributed control systems (DCS) in power plants and manufacturing
Petrochemical and refining process control
Wastewater and utility automation
Material handling and discrete machine control
Burner management and emergency shutdown systems
Remote actuator and solenoid control in industrial networks
Its rugged isolation and compatible output interfaces ensure dependable performance in diverse industrial settings.
Key Advantages
Isolated Output Channels
Eight individually isolated outputs enhance system safety and reduce electrical noise interference.
Built‑in Barrier Protection
Integrated isolation barriers protect both controller electronics and field devices.
Flexible Output Compatibility
Supports DC voltages up to 24 V and sinking or sourcing configurations for versatile field control.
Compact Industrial Packaging
The 100 × 70 × 35 mm footprint and 0.30 kg weight make it easy to install in rack or panel mount environments.
Wide Operating Range
Designed to operate reliably from -20 °C to +70 °C.
Technical FAQs
1. What is the Yokogawa ASD533 used for?
It is an 8‑channel digital output module designed to provide isolated discrete outputs in Yokogawa distributed control systems.
2. How many output channels does the module have?
It has 8 isolated digital outputs.
3. What output voltage and current does it support?
It supports up to 24 V DC and up to 1 A per channel.
4. Is this module isolated?
Yes — it includes 1500 V AC isolation barriers.
5. What are the module dimensions?
The physical size is 100 × 70 × 35 mm.
6. What is the weight of the module?
It weighs approximately 0.30 kg.
7. Can it be used in harsh environments?
Yes — it operates reliably from -20 °C to +70 °C, suitable for industrial automation.
8. What systems is it compatible with?
It is designed for Yokogawa CENTUM VP and CENTUM CS 3000 DCS platforms.
9. How fast does the module respond?
It typically responds within ≈10 ms for digital output switching.
10. Why choose the ASD533 in automation applications?
Because it offers isolated, high‑current digital outputs with built‑in protection and compact form factor, making it ideal for discrete control in process automation systems.
