Brand:Schneider PLC Item No.:ATS22C32S6 Product Origin:France Product Dimensions:425 x 206 x 299 mm Product Weight:33 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ATS22C32S6 belongs to Schneider Electric’s Altistart 22 series, designed for controlled starting and stopping of three-phase induction motors in heavy industrial environments. It uses voltage ramp technology combined with torque control to reduce inrush current and mechanical stress during motor startup and shutdown.
This model integrates SCR-based power control with an internal bypass system, ensuring efficient thermal management and stable long-term operation. Its robust construction and high current capacity make it suitable for demanding applications such as process industries, infrastructure systems, and heavy-duty manufacturing.
ATS22C25Q – Widely used in HVAC and pumping systems
ATS22C14Q – Common in conveyor and compressor applications
ATS480C32Q – Modern upgraded alternative for high-performance systems
Applications
The Schneider ATS22C32S6 Soft Starter Module is a high-capacity industrial motor control device designed for heavy-duty applications requiring controlled acceleration, reduced inrush current, and improved mechanical protection. It is widely used in demanding industrial environments where reliability and continuous operation are critical.
Typical applications include:
Large-scale water pumping and distribution systems
Industrial HVAC plants, chillers, and ventilation systems
High-capacity compressor installations
Conveyor systems for bulk and continuous material handling
Mining, cement, steel, and heavy manufacturing equipment
High-power three-phase induction motor drives in process industries
Its torque-controlled soft starting significantly reduces mechanical stress and electrical shock, improving system stability and extending equipment lifespan.
Advantages
High current capacity (320 A) suitable for heavy industrial motors
Smooth torque ramp reduces mechanical stress on driven equipment
Integrated bypass contactor improves thermal efficiency after start-up
Stable soft start/soft stop improves process reliability
Robust industrial-grade construction for harsh environments
Compatible with PLC and automation control systems
Built-in motor protection enhances operational safety
Reduces downtime and maintenance costs in continuous operation systems
Technical FAQs (10 Questions)
Q1: What type of motor is compatible with ATS22C32S6?
It is designed for three-phase asynchronous induction motors.
Q2: What is the rated current of this model?
It has a rated current of 320 A for standard industrial applications.
Q3: What is the supply voltage range?
It operates in the 230–600 V AC range depending on configuration.
Q4: What is the motor power range?
It supports approximately 90–220 kW depending on voltage level.
Q5: Does it include an internal bypass function?
Yes, it includes an integrated bypass contactor to reduce heat loss.
Q6: Can it be used in pump systems?
Yes, it is widely used in pumping applications to reduce water hammer effects.
Q7: Is it suitable for HVAC systems?
Yes, it is commonly applied in HVAC and ventilation systems.
Q8: Does it support PLC integration?
Yes, it integrates with standard industrial automation systems.
Q9: Does it support Modbus communication?
Yes, Modbus RTU communication is supported.
Q10: Can it be used for retrofit projects?
Yes, it is frequently used for upgrading existing motor control systems.
