The Schneider Electric ATV950D15N4 is a robust Altivar Process 950 series variable speed drive designed for high-demand industrial environments where reliability, energy optimization, and advanced motor control are essential.
Built for 15 kW heavy-duty applications, this drive delivers precise torque and speed regulation for pumps, conveyors, mixers, and complex process machinery. It is engineered as a “process-oriented intelligence node,” not just a traditional VFD, helping industries move toward fully digital, energy-efficient automation systems.
With IP55 protection, integrated communication protocols, and advanced diagnostics, the ATV950D15N4 is widely used in critical infrastructure where downtime is not an option.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ATV950D15N4 |
| Series | Altivar Process ATV950 |
| Device Type | Variable Speed Drive (VFD) |
| Rated Power | 15 kW (normal duty) |
| Supply Voltage | 380–480 V, 3-phase |
| Output Frequency | Up to 500 Hz |
| Output Current | Approx. 31.7 A |
| Control Modes | V/F, vector control, torque optimization |
| Protection Class | IP55 (dust & water resistant) |
| Communication | Ethernet/IP, Modbus TCP, PROFINET (via modules) |
| Overload Capacity | Up to 120–150% (depending on mode) |
| Installation | Wall-mounted, vertical ±10° |
Physical Dimensions & Weight
| Attribute | Value |
|---|---|
| Height | 678 mm |
| Width | 264 mm |
| Depth | 299 mm |
| Weight | ~19.6 kg (typical configuration) |
The IP55 rugged enclosure allows installation directly in harsh industrial environments without requiring full electrical cabinet protection.
Recommended Related Models
- Schneider Electric ATV950D11N4 (11 kW variant)
- Schneider Electric ATV930D15N4 (IP21 indoor alternative)
- Schneider Electric ATV950D18N4 (higher power range)
- Schneider VW3A Ethernet communication modules
- Schneider braking resistor kits for ATV900 series
These models allow scalable expansion across different load requirements and installation environments.
