The Schneider Electric ATV950D15N4E is part of the Altivar Process 950 series variable speed drive, designed for industrial motor control applications requiring stable performance, flexible integration, and energy optimization.
It is commonly used in pumping systems, conveyor lines, and process equipment where consistent motor regulation and system communication are required. The IP55-rated enclosure allows installation in more demanding environments compared to standard cabinet-mounted drives.
This model is positioned for industrial users looking for a balance between robustness, connectivity, and operational efficiency.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ATV950D15N4E |
| Series | Altivar Process 950 |
| Device Type | Variable Speed Drive (VSD/VFD) |
| Rated Power | 15 kW (typical application range) |
| Supply Voltage | 380–480 V, 3-phase |
| Control Methods | V/F control, vector control (depending on setup) |
| Communication | Ethernet/IP, Modbus TCP, Modbus RTU |
| Protection Rating | IP55 |
| Installation Type | Wall-mounted |
Physical Dimensions & Weight
| Attribute | Value |
|---|---|
| Height | 678 mm |
| Width | 264 mm |
| Depth | 330 mm |
| Weight | approx. 19–20 kg |
Recommended Related Models
- ATV950D11N4E – Lower power variant (11 kW)
- ATV930D15N4 – Indoor cabinet version
- ATV950D18N4E – Higher power variant
- Schneider VW3A communication modules
- Altivar Process accessory kits
