The Schneider Electric ATV950D45N4E is a 45 kW class Altivar Process 950 variable speed drive, designed for heavy industrial applications requiring stable motor control, high current handling, and advanced process integration.
It is commonly used in mining, water treatment, oil & gas, conveyors, crushers, mixers, and large-scale industrial automation systems. The drive is built for continuous-duty operation where reliability and controlled torque performance are critical.
With its IP55-rated enclosure and integrated switching design, it can be installed close to the machine, supporting decentralized layouts and reducing the need for full cabinet-based installations.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ATV950D45N4E |
| Series | Altivar Process ATV950 |
| Device Type | Variable Speed Drive (VFD) |
| Rated Power | 45 kW (normal duty) / 37 kW (heavy duty) |
| Supply Voltage | 380–480 V, 3-phase |
| Output Current | ~88 A nominal (depending on duty class) |
| Output Frequency | 0.1 – 500 Hz |
| Motor Compatibility | Asynchronous & synchronous motors |
| Control Modes | V/F control, vector control (application dependent) |
| Protection Class | IP55 |
| Communication | Ethernet/IP, Modbus TCP, Modbus RTU |
| Installation | Wall-mounted industrial enclosure |
Physical Dimensions & Weight
| Attribute | Value |
|---|---|
| Height | 910 mm |
| Width | 290 mm |
| Depth | 401 mm |
| Weight | approx. 52 kg |
The structure is designed for high thermal stability and long-duration industrial operation under heavy load conditions.
Recommended Related Models
- Schneider ATV950D37N4E – 37 kW heavy industrial applications
- Schneider ATV950D30N4E – 30 kW mid-high power systems
- Schneider ATV950D55N4E – next power step-up variant
- Schneider ATV930D45N4 – cabinet-mounted indoor version
- Schneider VW3A Ethernet / fieldbus communication modules
