The Schneider Electric ATV950U30N4 is a 3 kW class variable speed drive from the Altivar Process 950 series, designed for industrial process control applications requiring stable motor regulation, energy efficiency, and advanced connectivity.
It is commonly used in conveyors, pumps, mixers, crushers, light industrial automation systems, and water treatment equipment, where continuous operation and precise torque control are essential.
As part of Schneider Electric’s process-focused drive platform, it integrates monitoring, diagnostics, and communication functions that support modern digital industrial environments such as SCADA and IIoT systems. Its IP55-rated enclosure allows installation close to the machine in decentralized architectures.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ATV950U30N4 |
| Series | Altivar Process ATV950 |
| Device Type | Variable Speed Drive (VFD) |
| Rated Power | 3 kW (normal duty / heavy-duty derating applicable) |
| Supply Voltage | 380–480 V, 3-phase |
| Output Current | approx. 5.1–7.2 A depending on load condition |
| Output Frequency | 0.1 – 500 Hz |
| Motor Compatibility | Asynchronous & synchronous motors |
| Control Modes | V/F control, sensorless vector control |
| Overload Capacity | 120% (60 s) / up to 150% (derated mode) |
| Protection Class | IP55 |
| Communication | Modbus TCP, Ethernet/IP, Modbus RTU |
| Installation | Wall-mounted industrial enclosure |
Physical Dimensions & Weight
| Attribute | Value |
|---|---|
| Height | 678 mm |
| Width | 264 mm |
| Depth | 272 mm |
| Weight | approx. 10–11 kg (varies by configuration) |
The compact wall-mounted design is optimized for industrial reliability while keeping installation footprint minimal.
