The Schneider Electric BCH0601O12F1C is a 200 W AC servo motor from the Lexium BCH series, designed for precision motion applications requiring stable torque, fast response, and reliable positioning performance in compact automation systems.
Compared with brake-less variants, this model integrates a holding brake, making it especially suitable for vertical axes, stop-and-hold positioning, and safety-critical motion tasks where load retention is required during power-off conditions.
It is typically paired with Schneider Lexium servo drives (such as Lexium 23 Plus systems) and used in packaging machines, pick-and-place systems, labeling equipment, light robotics, and automated assembly lines. Its compact 60 mm frame allows easy integration into space-constrained industrial machinery.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | BCH0601O12F1C |
| Series | Lexium BCH |
| Device Type | AC Servo Motor |
| Rated Power | 200 W |
| Rated Voltage | 220 V AC, single-phase |
| Rated Current | approx. 1.55 A |
| Rated Speed | 3000 rpm |
| Maximum Speed | up to 5000 rpm |
| Rated Torque | approx. 0.64 N·m |
| Peak Torque | up to ~1.9 N·m (short duration) |
| Encoder Type | 20-bit high-resolution incremental encoder |
| Brake | Yes (holding brake integrated) |
| Shaft Type | Keyed shaft |
| Cooling Method | Natural convection |
| Protection Class | IP50–IP65 (depending on configuration) |
| Mounting Type | 60 mm flange industrial mounting |
Physical Dimensions & Weight
| Attribute | Value |
|---|---|
| Motor Length | approx. 105.5 mm |
| Flange Size | 60 mm |
| Shaft Diameter | ~14 mm |
| Key Size | ~5 mm |
| Weight | approx. 1.2 kg |
The compact mechanical structure is optimized for high-density automation layouts requiring precise motion control with minimal installation space.
Recommended Related Models
- Schneider BCH0601O11A1C – brake-less version for general positioning systems
- Schneider BCH0602O12F1C – higher torque two-stack variant with brake
- Schneider BCH0801O12F1C – medium-load servo applications
- Lexium 23 Plus Servo Drives – standard matching drive platform
- Lexium 32 Servo System – higher-performance motion control upgrade
