The Schneider Electric BCH0802O12A1C is a 0.75 kW AC servo motor from the Lexium BCH series, designed for high-dynamic precision motion control in industrial automation systems requiring stronger torque output and stable positioning performance.
It is widely used in packaging machines, automated assembly lines, CNC light-duty systems, robotics, and material handling equipment, where higher inertia handling and faster acceleration cycles are required compared to 60 mm frame servo motors.
This model is engineered for compatibility with Schneider Lexium servo drives (such as Lexium 23 Plus systems), forming a reliable closed-loop motion solution with high-resolution encoder feedback and stable torque delivery across a wide speed range.
The 80 mm frame size places it in the medium-power BCH category, making it suitable for applications that demand both precision and higher mechanical load capacity.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | BCH0802O12A1C |
| Series | Lexium BCH |
| Device Type | AC Servo Motor |
| Rated Power | 0.75 kW ([]) |
| Rated Voltage | 220 V AC, single-phase ([]) |
| Continuous Stall Current | 5.1 A ([]) |
| Rated Speed | 3000 rpm ([]) |
| Maximum Speed | up to 5000 rpm ([]) |
| Rated Torque Constant | 0.47 N·m/A ([]) |
| Encoder Type | 20-bit incremental encoder ([]) |
| Brake | Without holding brake |
| Shaft Type | Keyed shaft (Ø19 mm) ([]) |
| Cooling Method | Natural convection |
| Frame Size | 80 mm flange ([]) |
| Mounting Type | Industrial standard flange |
Physical Dimensions & Weight
| Attribute | Value |
|---|---|
| Motor Length | 138.3 mm ([]) |
| Shaft Diameter | 19 mm ([]) |
| Key Width | 6 mm ([]) |
| Weight | approx. 3.2–5.0 kg (depending on configuration) ([]) |
The design focuses on higher torque density and improved inertia handling, making it suitable for more demanding motion profiles than smaller BCH frame sizes.
Recommended Related Models
- Schneider BCH0802O12F1C – brake-equipped version for vertical load applications
- Schneider BCH0602O12A1C – lower power 60 mm frame alternative
- Schneider BCH0801O12A1C – lower inertia variant in 80 mm class
- Lexium 23 Plus Servo Drives – standard matching drive platform
- Lexium 32 Servo System – higher-performance motion control upgrade
