The Schneider Electric HMIET6500 is a 10.1-inch Human Machine Interface (HMI) from the Easy Harmony ET6 series, designed to deliver advanced machine visualization, operator control, and real-time process monitoring in modern industrial automation systems.

Built for OEM machinery and demanding production environments, the HMIET6500 combines a large widescreen display, responsive resistive touch interface, and stable industrial communication capabilities. It is widely applied in packaging lines, process automation, HVAC systems, water treatment plants, material handling systems, and factory automation, where clear visualization and reliable operation are essential.

With its enhanced screen size and flexible connectivity, it improves operator efficiency, reduces downtime, and supports smoother production management.

Technical Specifications

Parameter	Specification
Model	HMIET6500
Series	Easy Harmony ET6
Product Type	Human Machine Interface (HMI)
Display Type	TFT Color LCD
Screen Size	10.1-inch Widescreen
Resolution	1024 × 600 pixels (WSVGA)
Display Colors	16 Million Colors
Touch Technology	Single-touch resistive touchscreen
Processor	ARM Cortex-A8, 800 MHz
Memory	256 MB RAM / 128 KB backup memory
Operating System	VxWorks
Supply Voltage	24 V DC
Input Voltage Range	19.2–28.8 V DC
Communication Ports	Ethernet, RS-232, RS-422/RS-485, USB Host, USB Device
Programming Software	Vijeo Designer Basic
Real-Time Clock	Built-in
Front Protection	IP65
Rear Protection	IP20
Mounting Type	Panel mount

Mechanical Dimensions & Weight

Item	Specification
Width	270.5 mm
Height	200.5 mm
Depth	47 mm
Panel Cutout	255 × 185 mm
Panel Thickness	1.6–5 mm
Approximate Weight	0.99 kg

The larger 10.1-inch format improves visibility of industrial graphics, alarm systems, and process dashboards, making it suitable for operator-intensive environments.

Recommended Related Models

Schneider HMIET6400 – 7-inch compact HMI
Schneider HMIET6401 – 7-inch enhanced ET6 HMI
Schneider HMIET5400 – entry-level 7-inch HMI
Schneider HMIST6500 – alternative 10-inch Harmony ST series
Schneider Modicon M221 PLC
Schneider Modicon M241 PLC
Schneider Modicon M251 PLC

Popular Schneider Electric HMI Products

Easy Harmony ET6 Series
Easy Harmony ET5 Series
Harmony ST6 Series
Magelis Advanced HMI Series
Harmony GTU Series
Modicon PLC Integrated HMI Solutions

Typical Applications

The HMIET6500 is widely used across industrial sectors such as:

Packaging and bottling systems
Food and beverage production lines
Water and wastewater treatment plants
HVAC control systems
Conveyor and logistics automation
Textile and printing machines
Pharmaceutical manufacturing
OEM machine control panels
Energy management systems
General industrial automation

Its large display and stable system architecture help operators manage complex processes more efficiently and safely.

Key Advantages

Large 10.1-inch widescreen for improved process visibility
High-resolution 1024 × 600 display for clear graphics
Stable ARM Cortex-A8 processor for smooth operation
Multiple communication ports for flexible integration
IP65-rated front panel for industrial environments
Resistive touchscreen compatible with gloves operation
Built-in real-time clock for event tracking
Reliable VxWorks-based system stability
Easy integration with Schneider PLC ecosystem
Ideal for high-usage operator stations and OEM machinery

Technical FAQs

1. What is the HMIET6500 used for?
It is used for machine visualization, operator control, alarm management, and process monitoring in industrial automation systems.

2. What is the screen size and resolution?
It features a 10.1-inch TFT display with 1024 × 600 pixel resolution.

3. What is the operating voltage?
It operates on 24 V DC with an input range of 19.2–28.8 V DC.

4. Which communication interfaces are available?
It supports Ethernet, RS-232, RS-422/RS-485, USB Host, and USB Device ports.

5. What operating system does it use?
The HMI runs on the VxWorks embedded operating system.

6. Does it support real-time data tracking?
Yes, it includes a built-in real-time clock for event and alarm logging.

7. What is the protection rating?
The front panel is rated IP65 for industrial use.

8. What software is used for configuration?
It is programmed using Vijeo Designer Basic.

9. What industries commonly use this model?
Packaging, HVAC, water treatment, manufacturing, and process automation industries.

10. Why choose the HMIET6500?
Because it delivers a large display, stable performance, and flexible integration, making it ideal for complex industrial control and monitoring applications.
