The Schneider Electric HMIET6501 is a 10.1-inch Human Machine Interface (HMI) from the Easy Harmony ET6 series, designed for advanced machine visualization, operator interaction, and real-time industrial process control.
It delivers a high-quality widescreen display, stable processing performance, and flexible industrial communication capabilities, making it suitable for demanding automation environments. The HMIET6501 is widely used in packaging machinery, production lines, HVAC systems, water treatment plants, energy systems, and OEM equipment, where clear visualization and reliable control are essential for operational efficiency.
With its larger screen, expanded system memory, and multi-protocol communication support, it provides a strong balance between usability and industrial robustness.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | HMIET6501 |
| Series | Easy Harmony ET6 |
| Product Type | Human Machine Interface (HMI) |
| Display Type | TFT Color LCD |
| Screen Size | 10.1-inch Widescreen |
| Resolution | 1024 × 600 pixels (WSVGA) |
| Display Colors | 16 Million Colors |
| Touch Technology | Single-touch resistive touchscreen |
| Processor | ARM Cortex-A8, 800 MHz |
| Operating System | VxWorks |
| Memory | 256 MB RAM / 256 MB application memory |
| Storage Memory | 128 KB backup memory |
| Supply Voltage | 24 V DC |
| Input Voltage Range | 19.2–28.8 V DC |
| Power Consumption | Approx. 11 W |
| Communication Ports | 1× RS232, 1× RS422/RS485, Ethernet, USB |
| Programming Software | Vijeo Designer Basic |
| Real-Time Clock | Built-in |
| Brightness Levels | 16 levels |
| Front Protection | IP65 |
| Rear Protection | IP20 |
Mechanical Dimensions & Weight
| Item | Specification |
|---|---|
| Width | 271 mm |
| Height | 201 mm |
| Depth | 47 mm |
| Panel Cutout | 255 × 185 mm |
| Installation Panel Thickness | 1.6–5 mm |
| Approximate Weight | 0.99–1.53 kg |
The larger enclosure provides improved thermal stability and better operator visibility, especially in complex industrial control environments requiring continuous monitoring.
