The Schneider Electric HMIGTO1300 is a 3.5-inch Magelis GTO series industrial HMI panel, designed for compact machine control, basic process visualization, and operator interaction in small-scale automation systems.

It is part of Schneider Electric’s Harmony GTO platform, commonly used in OEM machinery where space is limited but stable human-machine interaction is required. The device combines a color touchscreen, function keys, and serial communication interfaces in a compact, rugged industrial housing.

It is widely applied in packaging machines, small conveyors, pumps, textile equipment, and general OEM automation systems.

Technical Specifications

Parameter	Specification
Model	HMIGTO1300
Series	Harmony / Magelis GTO
Product Type	Compact Touchscreen HMI Panel
Display Type	TFT Color LCD
Screen Size	3.5-inch
Resolution	320 × 240 (QVGA)
Display Colors	65,536 colors
Touch Technology	Resistive touchscreen
Function Keys	6 programmable keys
Supply Voltage	24 V DC
Input Voltage Range	19.2–28.8 V DC
Communication Ports	RS-232 / RS-485 / RS-422
USB Ports	USB + Mini USB
Memory	64 MB application memory
Programming Software	Vijeo Designer
Protection Rating	IP65 front panel
Mounting Type	Panel mount

Mechanical Dimensions & Weight

Item	Specification
Width	132 mm
Height	106 mm
Depth	42 mm
Panel Cutout	118.5 × 92.5 mm
Weight	Approx. 0.4 kg

Its compact size makes it ideal for tight control cabinets and small machine enclosures.

Recommended Related Models

Schneider HMIGTO1310 – enhanced memory version
Schneider HMISTU series compact HMIs
Schneider HMIET5400 – entry-level ET5 series
Schneider HMIET6400 – 7-inch ET6 HMI
Schneider Modicon M221 PLC
Schneider Modicon M241 PLC

Popular Schneider Electric HMI Families

Magelis GTO Compact HMI Series
Harmony STU Compact Panels
Easy Harmony ET5 / ET6 Series
Magelis Advanced HMI Platforms
Modicon PLC Integrated Systems

Typical Applications

The HMIGTO1300 is commonly used in:

Small packaging machines
Conveyor systems
Pump and fan control panels
OEM machinery interfaces
Basic process automation systems
Textile and auxiliary machines
Food and beverage compact equipment
Entry-level industrial control panels
Laboratory and testing equipment
Simple production systems

Key Advantages

Ultra-compact industrial HMI design
Easy operation with touch + function keys
Stable performance for OEM machine control
Multiple serial communication options
IP65-rated front panel protection
Low power industrial operation
Simple integration with PLC systems
Reliable long-term machine interface
Space-saving panel installation
Cost-efficient automation solution

Technical FAQs

1. What is the HMIGTO1300 used for?
It is used for basic machine control and operator interface in compact industrial systems.

2. What is the display size?
It features a 3.5-inch color touchscreen.

3. What is the resolution?
The display resolution is 320 × 240 pixels (QVGA).

4. Does it support physical keys?
Yes, it includes 6 programmable function keys.

5. What power supply does it require?
It operates on 24 V DC industrial power.

6. What communication interfaces are available?
It supports RS-232, RS-485, RS-422, and USB interfaces.

7. What software is used for configuration?
It is programmed using Vijeo Designer.

8. Is it suitable for harsh environments?
Yes, it has IP65 front protection for industrial use.

9. What industries commonly use it?
OEM machinery, packaging, and small automation systems.

10. Why choose HMIGTO1300?
Because it provides a compact, reliable, and cost-effective operator interface for simple industrial automation applications.
