The Schneider Electric HMIGTO4310 is a 7.5-inch Magelis GTO series industrial HMI panel, designed for machine visualization, operator control, and industrial process interaction in OEM and factory automation environments.
As part of the Harmony GTO platform, it delivers a reliable human-machine interface with a color touchscreen, multi-protocol communication capability, and rugged industrial design. It is widely used in applications where stable PLC connectivity, clear visualization, and continuous operation are required.
This model is commonly found in packaging machines, production lines, material handling systems, food & beverage equipment, and general industrial automation systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | HMIGTO4310 |
| Series | Magelis / Harmony GTO |
| Product Type | Advanced Touchscreen HMI Panel |
| Display Type | TFT Color LCD |
| Screen Size | 7.5-inch |
| Resolution | 640 × 480 (VGA) |
| Display Colors | 65,536 colors |
| Touch Technology | Resistive touchscreen |
| Processor | RISC industrial CPU (~333 MHz class) |
| Memory | 96 MB onboard memory |
| Supply Voltage | 24 V DC |
| Input Voltage Range | 19.2–28.8 V DC |
| Communication Ports | RS-232 / RS-422 / RS-485 |
| Ethernet | Supported (industrial networking) |
| USB Interfaces | USB Host + Mini USB |
| Storage | SD card supported |
| Programming Software | Vijeo Designer |
| Real-Time Clock | Built-in |
| Protection Rating | IP65 front panel (industrial sealing) |
Mechanical Dimensions & Weight
| Item | Specification |
|---|---|
| Width | 218 mm |
| Height | 173 mm |
| Depth | 60 mm |
| Panel Cutout | Approx. 201 × 157 mm |
| Weight | ~1.2 kg |
The 7.5-inch form factor provides a balanced viewing area while maintaining a compact footprint suitable for standard industrial control cabinets.
