Brand:Schneider PLC Item No.:Schneider HMIGXU3500 Product Origin:France Product Dimensions:207 × 150 × 40 mm Product Weight:0.55 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider HMIGXU3500 is a compact industrial HMI panel from the Harmony Easy GXU series, designed for machine-level control applications where space efficiency and stable operator interaction are essential. It provides a simple yet reliable interface between operators and automation systems, supporting real-time monitoring, alarm handling, and basic process control.
This model is typically selected for small to mid-sized machines where cost efficiency, ease of integration, and dependable communication are more important than high-end graphical complexity. Despite its compact form factor, it delivers solid industrial-grade performance suitable for continuous operation environments.
Technical Specifications
Item
Specification
Brand
Schneider Electric
Series
Harmony Easy GXU
Model
HMIGXU3500
Product Type
Compact HMI Operator Panel
Display Size
7.0 inch TFT LCD
Resolution
800 × 480 (WVGA)
Display Colors
65,536 colors
Touch Type
Resistive touchscreen
Power Supply
24 V DC
Communication Ports
Serial (RS232 / RS485), USB Mini-B
Protocol Support
Modbus RTU, Modbus TCP (via system configuration)
Application Memory
~32 MB
Backup Memory
~128 KB
Operating Temperature
0°C to 50°C
Front Protection
IP65 (when panel mounted correctly)
Mounting Type
Panel mount
Programming Software
Vijeo Designer Basic
Dimensions
Approx. 207 × 150 × 40 mm
Weight
Approx. 0.55 kg
The lightweight design makes it easy to install in compact control cabinets while maintaining stable industrial performance.
Recommended Related Models
Model
Description
HMIGXU3510
Similar GXU compact HMI variant
HMIGTO2310
Entry-level Harmony GTO HMI
HMIGTO3310
Mid-range compact operator panel
HMIGTO5310
Advanced 10.4-inch HMI
HMIGXU5512
Higher-performance GXU series panel
HMISTO705
Basic touchscreen HMI solution
Popular Schneider HMI Models
Model
Category
HMIGXU3500
Compact GXU HMI
HMIGXU3510
Compact GXU variant
HMIGTO5310
Standard industrial HMI
HMIGTO5315
Stainless steel HMI panel
HMIGTO6310
Large-format HMI
HMIGXU5512
Advanced GXU HMI
HMISTO705
Entry-level HMI
XBTGT5330
Legacy Magelis panel
Applications
The HMIGXU3500 is widely used in compact automation systems where simple visualization and reliable control are required. Typical applications include:
Small packaging machinery
HVAC control systems
Pumping and water systems
Textile production equipment
Light manufacturing machines
Conveyor control systems
Building automation panels
OEM machine integration
Its compact size and straightforward functionality make it especially suitable for cost-sensitive industrial projects.
Key Advantages
Compact 7-inch design suitable for space-limited installations
Stable 24 V DC industrial operation
Easy integration with Schneider PLC systems
Lightweight structure for simplified panel mounting
Reliable resistive touchscreen for industrial environments
Supports common industrial communication protocols
Cost-effective solution for machine-level control
IP65 front protection for industrial durability
Simple configuration using Vijeo Designer Basic
Proven performance in small to mid-scale automation systems
Technical FAQs
Q1. What is the HMIGXU3500 used for?
It is used as a compact operator interface for controlling and monitoring small industrial machines.
Q2. What is the screen size?
It features a 7-inch TFT LCD display.
Q3. Is it suitable for industrial environments?
Yes, it is designed for light to medium industrial automation applications.
Q4. What communication interfaces does it support?
It supports RS232, RS485, and USB communication ports.
Q5. Can it connect to PLC systems?
Yes, it supports Modbus and other standard industrial protocols for PLC integration.
Q6. What is the power supply requirement?
It operates on 24 V DC industrial power.
Q7. What is the protection rating?
The front panel is IP65 rated when properly installed.
Q8. What software is used for configuration?
It is programmed using Vijeo Designer Basic software.
Q9. What industries commonly use this model?
It is used in HVAC, packaging, pumping, textile, and small automation systems.
Q10. Why choose this model over larger HMIs?
It is more compact, cost-efficient, and ideal for machines that do not require advanced visualization.
