The Bently Nevada 330704-000-050-90-02-05 is an 11 mm proximity probe from the 3300 XL series, engineered for non-contact measurement of shaft vibration and displacement in rotating machinery.
It is part of the eddy current proximity transducer system and operates together with a Proximitor sensor and extension cable. This system is widely used in turbines, compressors, pumps, and generators for continuous condition monitoring and machinery protection.
The 050 / 90 / 02 / 05 configuration generally represents:
- 050 = 50 mm case length
- 90 = 9.0 m system cable length
- 02 = ClickLoc miniature coaxial connector system
- 05 = Multiple approval / compliance variant (often used for broader industrial certification requirements)
The 3300 XL 11 mm probe family provides a typical linear measurement range of around 4 mm (160 mil), making it suitable for reliable shaft vibration monitoring in fluid-film bearing machines.
Technical Specifications
| Item | Specification |
|---|---|
| Brand | Bently Nevada |
| Series | 3300 XL |
| Model | 330704-000-050-90-02-05 |
| Product Type | 11 mm Proximity Probe |
| Measurement Type | Non-contact vibration / displacement |
| Technology | Eddy current sensing |
| System Compatibility | 3300 XL Proximitor system |
| Probe Tip Size | 11 mm |
| Output Signal | Analog displacement signal |
| Installation Type | Thread-mounted probe assembly |
| Connector System | ClickLoc miniature coaxial connector |
| Case Length | 50 mm |
| System Cable Length | 9.0 m |
| Approval Option | “05” multi-approval variant |
| Material | Stainless steel probe body |
| Application | Rotating machinery monitoring systems |
Dimensions & Weight
| Item | Specification |
|---|---|
| Dimensions (L × W × H) | Approx. 50 mm × 10–12 mm × 10–12 mm |
| Weight | Approx. 0.2–0.3 kg |
Note: Actual dimensions may vary slightly depending on installation configuration and cable routing.
System Configuration
This probe is part of a complete 3300 XL measurement chain:
- 3300 XL 11 mm proximity probe
- Matching extension cable (9.0 m)
- 3300 XL Proximitor sensor
The system converts shaft motion into a proportional electrical signal used for vibration monitoring, diagnostics, and machinery protection.
Recommended Related Models
| Model | Description |
|---|---|
| 330704-000-050-10-02-00 | Standard approval variant |
| 330704-000-050-90-02-00 | Same configuration without “05” approval option |
| 330704-000-030-90-02-00 | Alternative case/cable configuration |
| 330704-000-040-10-02-05 | Compact version |
| 330703 Series | 11 mm proximity probe family |
| 3300 XL Extension Cable | Signal transmission component |
