Brand:GE Fanuc PLC Item No.:IC200MDL640 Product Origin:USA Product Dimensions:110 mm × 50 mm × 66.8 mm Product Weight:0.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200MDL640 VersaMax Discrete Input Module is designed for industrial automation systems requiring reliable digital signal acquisition. As part of the VersaMax I/O family, this module provides 16 discrete input channels for monitoring field devices connected to PLC control systems.
The module supports 24VDC positive and negative logic input configurations and is commonly used in machine control, process monitoring, and distributed I/O applications. Its compact design allows engineers to expand control systems while maintaining efficient panel space utilization.
With clear LED status indication and flexible input configuration, the IC200MDL640 provides a practical solution for industrial applications requiring dependable digital input collection.
Technical Specifications
Specification
Details
Product Model
GE IC200MDL640
Product Type
VersaMax Discrete Input Module
Input Type
Digital / Discrete Input
Number of Inputs
16 Points
Input Groups
2 Groups of 8 Inputs
Input Voltage Range
0 to 30VDC
Nominal Input Voltage
24VDC
Logic Type
Positive / Negative Logic
Input Impedance
10 kΩ
Input Response Time
Approx. 0.5 ms
LED Indicators
Individual Point LEDs and OK Status LED
Backplane Current Consumption
5VDC, 25mA Maximum
External Power Supply
Not Required
Isolation
Group and logic isolation protection
Dimensions
Approx. 110 mm × 50 mm × 66.8 mm
Weight
Approx. 0.11 kg
Recommended Companion Models
Model
Product Name
IC200CPU001
GE Fanuc VersaMax CPU Module
IC200MDL650
GE Fanuc VersaMax 32-Point Discrete Input Module
IC200MDL750
GE Fanuc VersaMax Relay Output Module
IC200PWR102
GE Fanuc VersaMax Power Supply Module
Frequently Selected Alternatives
Model
Product Name
IC200MDL650
GE Fanuc VersaMax 32-Point Discrete Input Module
IC200MDL643
GE Fanuc VersaMax 5/12VDC TTL Input Module
IC200MDL644
GE Fanuc VersaMax 5/12VDC TTL Input Module
BXIOID1624
Emerson VersaMax 16-Point 24VDC Input Module
Where It Excels in Industrial Use
• PLC Digital Input Applications
Designed for industrial control systems that require reliable monitoring of switches, sensors, and field input devices.
• Machine Automation Systems
Suitable for production equipment, assembly lines, and automated machinery using 24VDC discrete signals.
• Process Control Monitoring
Used for collecting ON/OFF status information from field devices in industrial process applications.
• Distributed I/O Systems
Works as part of GE Fanuc VersaMax I/O platforms where compact and flexible input expansion is required.
Key Strengths at a Glance
• 16-Point Discrete Input Design
Provides 16 digital input channels arranged in two groups of eight points for flexible field wiring.
• 24VDC Positive/Negative Logic Support
Supports 24VDC input applications with selectable positive or negative logic configurations depending on module version.
• Fast Input Response
Provides a basic input response time of approximately 0.5 ms, suitable for many industrial switching applications.
• Compact VersaMax Architecture
Designed for space-efficient PLC and distributed control installations using VersaMax modular I/O systems.
Technical FAQs
1. What type of module is GE IC200MDL640?
GE IC200MDL640 is a VersaMax discrete input module designed to collect digital ON/OFF signals from field devices.
2. How many input points does the IC200MDL640 provide?
The module provides 16 discrete input points divided into two groups of eight inputs.
3. What input voltage does the IC200MDL640 support?
The module supports 0 to 30VDC input signals with 24VDC nominal operating voltage.
4. Can the IC200MDL640 handle positive and negative logic inputs?
Yes, the module supports positive and negative logic input configurations, with negative logic functionality depending on the module revision.
5. Does this module require an external power supply?
No, the module receives operating power from the VersaMax backplane.
6. What field devices can connect to this input module?
Typical connected devices include switches, proximity sensors, pushbuttons, and other discrete signal devices.
7. How is input status displayed on the module?
Each input point has an LED indicator showing the ON/OFF status, along with an OK LED for module power status.
8. What PLC system is compatible with IC200MDL640?
The module is designed for GE Fanuc VersaMax PLC and distributed I/O systems.
9. What is the input impedance of this module?
The input impedance is approximately 10 kΩ.
10. What should be checked before replacing an IC200MDL640 module?
The user should confirm module model, input voltage requirements, wiring configuration, and VersaMax system compatibility.
