Brand:GE Fanuc PLC Item No.:IC200PWR101B Product Origin:USA Product Dimensions:49 mm × 133.4 mm × 39 mm Product Weight:0.12 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200PWR101B VersaMax Power Supply Module is designed for industrial automation systems requiring dependable power distribution within VersaMax PLC installations.
This module accepts 120/240VAC input and provides regulated 5VDC and 3.3VDC outputs for VersaMax CPUs, network interface units, and I/O modules. Its compact modular structure allows efficient installation in control cabinets while supporting scalable automation system designs.
The IC200PWR101B is commonly used in manufacturing equipment, process control applications, and distributed PLC systems where stable backplane power is essential for reliable operation.
Technical Specifications
Specification
Details
Product Model
GE IC200PWR101B
Product Type
VersaMax Power Supply Module
Input Voltage
120/240VAC
Input Voltage Range
85 to 132VAC / 176 to 264VAC
Input Frequency
47 to 63Hz
Input Power
27VA
Output Voltage
5VDC and 3.3VDC
Total Output Current
1.5A Maximum
3.3VDC Output Current
0.25A Maximum
Protection
Short Circuit Protection, Overload Protection
Holdup Time
Approx. 20ms
Application
VersaMax CPU, NIU and I/O Module Power Supply
Mounting Type
VersaMax Modular Mounting
Dimensions
Approx. 49 mm × 133.4 mm × 39 mm (excluding carrier/DIN rail height)
Weight
Approx. 0.12 kg
Recommended Companion Models
Model
Product Name
IC200CPU001
GE VersaMax CPU Module
IC200MDL640
GE VersaMax 24VDC 16-Point Discrete Input Module
IC200MDL750
GE VersaMax Relay Output Module
IC200PWB001
GE VersaMax Power Supply Booster Carrier
Frequently Selected Alternatives
Model
Product Name
IC200PWR102
GE VersaMax 120/240VAC Power Supply Module with Expanded 3.3VDC Capacity
IC200PWR001
GE VersaMax 24VDC Power Supply Module
IC200PWR002
GE VersaMax 24VDC Expanded Power Supply Module
IC200PWR201
GE VersaMax 120/240VAC Power Supply Module
Where It Excels in Industrial Use
• VersaMax PLC System Power Supply
Designed to provide stable backplane power for GE Fanuc VersaMax CPUs, network interface units, and I/O modules in industrial automation systems.
• Industrial Control Cabinet Applications
Suitable for machine control panels, factory automation equipment, and distributed control systems requiring compact power management.
• PLC Expansion Systems
Used in VersaMax configurations where additional I/O modules require reliable system power distribution.
• Automation Equipment Upgrades
Applied in existing control systems requiring replacement or maintenance of VersaMax power supply components.
Key Strengths at a Glance
• 120/240VAC Input Design
Supports common industrial AC power sources with selectable input configuration for different installation requirements.
• VersaMax Modular Integration
Designed to mount directly with VersaMax CPU, NIU, or booster carrier configurations.
• Dual DC Output Supply
Provides 5VDC and 3.3VDC outputs required by VersaMax system modules.
• Built-In Protection Functions
Includes short-circuit and overload protection to support reliable industrial operation.
Technical FAQs
1. What is the GE IC200PWR101B Power Supply Module used for?
The IC200PWR101B is used to provide operating power for GE Fanuc VersaMax PLC system modules.
2. What type of input power does the IC200PWR101B require?
The module supports 120VAC or 240VAC nominal input power configurations.
3. What output voltages does the IC200PWR101B provide?
The module provides 5VDC and 3.3VDC outputs for VersaMax system power requirements.
4. What is the maximum output current of this power supply?
The module provides a maximum combined output current of 1.5A across the 5VDC and 3.3VDC outputs.
5. Can this module supply power to VersaMax I/O modules?
Yes, it is designed to provide backplane power for VersaMax CPUs, network interface units, and I/O modules.
6. What protection features are included in this power supply?
The module includes short-circuit protection and overload protection functions.
7. What is the input frequency range of the IC200PWR101B?
The supported input frequency range is 47 to 63Hz.
8. Can the IC200PWR101B be used as an additional power source?
Yes, it can be used as a supplemental power source when installed with a compatible booster carrier.
9. What PLC platform is compatible with this module?
The module is designed for GE Fanuc VersaMax PLC and distributed I/O systems.
10. What should be confirmed before replacing this power supply module?
The input voltage configuration, VersaMax system compatibility, module position, and power requirements should be checked before replacement.
